Daewoo DLT-26C2 Service Manual

-23-
Description of Each Block
C.CN2 Pin Spec(YEON-HO YW025-04 4P)
PIN No.
1
2
3
4
Output
+29V
+29V
GND
GND
D.CN4 Pin Spec(YEON-HO SMW025-09 9P)
PIN No.
1
2
3
4
Output
+12V
+12V
GND
GND
5
+5VS
6
PWR ON/OFF
7
GND
8
GND
9
+5VS
E.CN3 Pin Spec(CA3237W-300-08P)
PIN No.
1
2
3
4
Output
DIMIMING
INV ON/OFF
N/C
GND
5
GND
6
7
8
+5VS
+5VS
+12V
