-89-
ZZ100 48B5655J12 TRANSMITTER REMOCON R-55J12(AAA)
ZZ110 PTACPWG262 ACCESSORY AS DLT-37C3LMBD
60 4850Q00910 BATTERY R03/NN
M212 4852177601 COVER BOTTOM HIPS BK
M681 4856819300 CLAMP WIRE NYLON 66
M821 4858219401 BAG INSTRUCTION L.D.P.E T0.05X280X470
M861 4.86E+08 MANUAL INSTRUCTION ENGLISH
P801A 48599PM005 CORD POWER AS UK LP-61L+LS-60=2.0M(CORE)
ZZ120 PTBCSHG262 COVER BACK AS DLT-37C3LMBD
M211 4852177501 COVER BACK HIPS BK
M211C 4855944700 DECO TERM B PC 0.25T
M388 4853829200 FRAME WALL KIT SECC T=2.0
M388A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
ZZ130 PTPKCPG262 PACKING AS DLT-37C3LMBD
M801 4858071600 BOX CARTON DW-3
M811 485819CT00 PAD EPS
M822 4858215001 BAG P.E PE FOAM t0.5x1200x1150
ZZ140 PTCACAG262 CABINET AS DLT-37C3LMBD
J10A 4859006761 CABLE LVDS LPL:FMW1214A-31A+FH10001-3
M191 4851958700 SHIELD CASE AS 7256400+5944605
M201A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M211A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M211B 7172401652 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 3CR
M211C 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M321 4853297000 BRKT STAND SECC T1.6
M321A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M322 4853296700 BRKT STAND BOX SECC T1.0
M322A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M381A 7178300852 SCREW TAPPTITE TT2 WAS 3X8 MFZN BK 3CR
M382 4853829800 FRAME SURPORT SECC T1.2
M382A 7003400651 SCREW MACHINE BIN 4X6 MFZN 3CR
M383 4853829400 FRAME SIDE T SECC T1.2 (LPL)
M383A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M383B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M384 4853829600 FRAME SIDE B SECC T1.6 (LPL)
M384A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M384B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M384C 4856815900 CLAMP WIRE EGI T0.4+TUBE+PIE 3.2
M385 4853830000 FRAME SIDE L/R SECC T1.2 (LPL)
M385A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M491B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M541 4855421200 SPEC PLATE P.E 149X59
M681 4956800200 CLAMP WIRE WS-A-2-19
M721A 7178300852 SCREW TAPPTITE TT2 WAS 3X8 MFZN BK 3CR
M723 4857255905 SHIELD JACK AL 1100 T=1.0 (A-6 : SL-50
M723A 7178300852 SCREW TAPPTITE TT2 WAS 3X8 MFZN BK 3CR
P803B 4850712S11 CONNECTOR 20022HS-12S+20022HS-12S+UL
P803C 4850712S09 CONNECTOR 20022HS-12S+20022HS-12S+UL
V901 485LD00370 LCD PANEL LC370WX1-SL01
V902 4850M14510 MODULE POWER FEL-37H
ZZ200 PTFMSJG262 MASK FRONT AS DLT-37C3LMBD
M201 4852094001 MASK FRONT HIPS BK
M201A 4857743800 CUSION PANEL PVC 400 X 10 T=1.0
M561 4855625700 MARK BRAND SILVER DIA-CUTTING(DOUBLE
M591 4855945400 DECO PLATE PC T2.0
ZZ210 PTSPPWG262 SPEAKER AS DLT-37C3LMBD
SP01 48A8317000 SPEAKER SYSTEM SS-57165F01CR
SP01A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
SP02 48A8317000 SPEAKER SYSTEM SS-57165F01CR
SP02A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
SP03A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
SP04A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
ZZ250 PTSNSWG229 STAND AS DLV-37C3LMBS
M387 4853831201 FRAME STAND ABS BK
M387A 7115401552 SCREW TAPPING FLT 4X15 MFZN BK 3CR
M520 4851957501 COVER ASSY STAND SUB ASSY (NORMAL SPR
ZZ290 PTMPMSG262 PCB MAIN MANUAL AS DLT-37C3LMBD
100 2193110012 SOLDER WIRE SAC3000 •’3.0MM (LFA3C0-W3
200 2193110024 SOLDER WIRE SAC3005 •’1.6MM (LFA3-107-
300 2291050623 FLUX SOLDER LF SV-PBF-304P(0.823)
LOC PART CODE PART NAME DESCRIPTION
400 2291050312 FLUX SOLVENT S-3000
C0N1 4859200440 CONN PCMCIA PC68PRA5513XZ
JP1 4859112950 JACK SCART DSSM-0378 STR
JP10 4859105340 JACK S-VHS DSW-10 (STRAIGHT)
JP11 4859117450 JACK PIN DPSS-0173S(3P ST SHIELD)
JP2 4859112950 JACK SCART DSSM-0378 STR
JP3 4859117550 JACK PIN DPSE-0375S
JP4 4959102340 JACK PHONE SPJ-358H(3.5 STRAIGHT)
JP6 4959200160 CONN D-SUB SHF-015-B111-22/BR2-J0.6
JP7 97P6316100 JACK HEAD PHONE DHSE-9959
JP8 4859201170 CONN OPTICAL SENSOR OJ107A-T050-SHS
JP9 4859201460 CONN D-SUB 9P SHRA0209011
M321 4853294100 BRKT POWER SW SECC 1T
M321A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M371 4853748800 RETA PCB NYLON 66
M372 4956800200 CLAMP WIRE WS-A-2-19
M381 4855218900 PLATE LOWER “SECC, T=1.2”
M381B 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M381C 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M381D 7008300851 SCREW MACHINE WAS 3X8 MFZN 3CR
M381E 4856815900 CLAMP WIRE EGI T0.4+TUBE+PIE 3.2
M381F 4956800200 CLAMP WIRE WS-A-2-19
P13A 4850705S34 CONNECTOR 20017HR-05+12505HS-05+USW=
P14A 4850706S49 CONNECTOR 20017HR-06+12505HS-06+USW=
P4 4859284420 CONN WAFER SMW250-03
P5 4959240520 CONN WAFER SMW250-02
P6 4859285020 CONN WAFER SMW250-09
P6A 4850709S21 CONNECTOR SMH250-09+SMH250-09+ULW=30
P7 4859284920 CONN WAFER SMW250-08
P8A 4850704S86 CONNECTOR YH025-04+YH025-04+ULW=300
P9 4859295520 CONN WAFER 4602-02MV2-60-1 PLUG 2P ST
TU1 4859731230 TUNER DIGITAL TD1318AF/IHP-3(DV-IF-H-P)
U10 125L8005PC IC FLASH MEMORY MX25L8005PC-15G 8M 8-DIP
U11 1M24C32BN6 IC EEPROM M24C32WRN6
U3 1M24C04BN6 IC EEPROM M24C04WRN6
U31 14C64WBN6- IC EEPROM M24C64-WBN6
X2 5XJ14R31AE CRYSTAL QUARTZ HC-49/S 14.31818MHZ 30PPM
Z1 5PK9650M— FILTER SAW K9650M
Z2 5PK3953M— FILTER SAW K3953M
ZZ200 PTMPJ2G262 PCB MAIN CHIP B AS DLT-37C3LMBD
C10 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C100 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C105 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C12 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C13 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C132 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C136 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C14 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C145 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C15 HCBK472KBA C CHIP CERA 50V X7R 4700PF K 1608
C16 HCBK472KBA C CHIP CERA 50V X7R 4700PF K 1608
C164 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C166 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 1608
C168 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 1608
C17 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
C171 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C172 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C176 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C177 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C182 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C183 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C184 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C185 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C186 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C187 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C188 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C189 HCBK222KBA C CHIP CERA 50V X7R 2200PF K 1608
C19 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
C190 HCBK153KBA C CHIP CERA 50V X7R 0.015MF K 1608
C191 HCBK221KBA C CHIP CERA 50V X7R 220PF K 1608
LOC PART CODE PART NAME DESCRIPTION
DLT-37C3
Service part list
