- 2 -
1.2 Information
Disk Format
DVD, VCD, CD, CD-R, CD-RW, MP3, Kodak
Picture CD
Video :
Video System
NTSC / PAL
Video Decompression MPEG-4, MPEG-2, MPEG-1
Video Output
1.0 Vpp / 75Ω Sync , minus
Audio :
Audio Characteristic 2 – Channel Analog
5.1 – Channel digital output
Analog Output
2.0 V / 10KΩ
Frequency Response
DVD : 48 KHz sampling : 4Hz ～ 22 KHz
96 KHz Sampling : 4Hz ～ 44 KHz
CD : 4Hz ～ 20KHz
S / N ratio < = - 65 dB
Dynamic Range < = - 85 dB
Distortion < = 0.01 %
Digital Output SPDIF
Speaker Stereo speakers, 0.5W x 2
Headphone Jack
LCD Display 7", 8” wide-screen active-matrix TFT type
Terminal :
Headphone Headphone Jack
Audio / Video Section Audio output jack x1
Video output jack x1
P-scan output x1
Coaxial output jack x1
SD/ MMC memory card reader (option) x1
USB host (option) x1
Power Adaptor :
Line Voltage
AC 100 - 240 VAC ± 10% (50/60Hz) Adapter
Power Consumption 15W
Remote Control DC 3V , Infra – red
Dimension 210 x 155 x 43.2 (mm)
Weight 740g (around)
