46
◆
DSA-185L, 185P PART LIST (Control PCB Assy)
No. PART CODE PART NAME SPEC. Q'TY UNIT REMARK
CA1 CN5XD104M- C-ARRAY 6P(F5)X 104Z 1 EA
CA2 CN3XD104M- C-ARRAY 4P(F3)X 104Z 1 EA
CC1 CCXE1E104M C-CERA 104Z 25VDC 1 EA
CC13 CDXE1H104M C-MULTI CR501B-Z5U,104Z,50V 1 EA
CC2 CCXE1E104M C-CERA 104Z 25VDC 1 EA
CC3 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC4 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC5 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC6 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC7 CCXE1E104M C-CERA 104Z 25VDC 1 EA
CC8 CCXE1H103M C-CERA 103M 50VDC 1 EA
CC9 CCXE1H103M C-CERA 103M 50VDC 1 EA
CE1 CEXE1C475A C-ELEC 4.7UF 50V SS 1 EA
CE2 CEXE1C106A C-ELEC 10UF 16V SS 1 EA
CN1 3108802400 WAFER SMAW250-10(RED) 1 EA
CN2 3108804100 WAFER SMW250-07 1 EA
CN3 3108804200 WAFER SMW250-02(RED) 1 EA
CN4 3108802010 WAFER SMW250-06(RED) 1 EA
CN5 3108802000 WAFER SMW250-06 1 EA
CN6 3108802000 WAFER SMW250-06 1 EA
CN8 3108804500 WAFER 5267-04A 1 EA
D1 DZN4148FTB DIODE 1N4148 AUTO 26MM 1 EA
F1 3109400050 JUMPER 5MM 1 EA
IC1 13GS5DH9-- MICOM (MAIN) TMP87C846N-5DH9(Z) 1 EA
IC2 1KA7042P-- IC RESET KIA7042P 5L 1 EA
IC3 13GT62004A IC DRIVER ULN2004AP(M) 1 EA
IC4 13GT62004A IC DRIVER ULN2004AP(M) 1 EA
JS1 3109400100 JUMPER 10MM 1 EA
JS3 3109400100 JUMPER 10MM 1 EA
OSC1 5PCRTL8MS0 RESONATOR CRTL8.00MSOT 1 EA
PCB 3104397163 PCB CONTROL 110*90.5*1.6T(99) 1 EA
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
