48
No. PART CODE PART NAME SPEC. Q'TY UNIT REMARK
BZ1 3105698200 BUZZER DP-2520BA 1 EA
C1 CLV-B3104M C-LINE ACROSS 275V 104K(PILKOR) 1 EA
C2 CLV-B3104M C-LINE ACROSS 275V 104K(PILKOR) 1 EA
CC1 CCXE1E104M C-CERA 104Z 25VDC 1 EA
CC2 CCXE1E104M C-CERA 104Z 25VDC 1 EA
CC3 CCXE1E104M C-CERA 104Z 25VDC 1 EA
CC4 CCXE1H103M C-CERA 103M 50VDC 1 EA
CE1 CEXE1V228C C-ELEC 2200UF/35V RS 1 EA
CE2 CEXE1E477C C-ELEC 470MF 25V SD 1 EA
CE3 CEXE1C107C C-ELEC 100MF 16V SD 1 EA
CLIP 3107000600 FUSE CLIP AFC-520 2 EA
CN1 3108803900 WAFER YW396-05AV(RED) 1 EA
CN2 3108803800 WAFER YFW800-02 1 EA
CN3 3108802900 WAFER YW396-05AV 1 EA
CN4 3108802500 WAFER YW396-03AV 1 EA
CN5 3108802800 WAFER YW396-03AV(BLUE) 1 EA
CN6 3108802100 WAFER SMW250-10 1 EA
CN7 3108800320 WAFER 5281-02A 1 EA
D1 DZN4004A-- DIODE KN4004A AUTO 52MM 1 EA
D2 DZN4004A-- DIODE KN4004A AUTO 52MM 1 EA
D3 DZN4004A-- DIODE KN4004A AUTO 52MM 1 EA
D4 DZN4004A-- DIODE KN4004A AUTO 52MM 1 EA
D5 DZN4004A-- DIODE KN4004A AUTO 52MM 1 EA
D6 DZN4004A-- DIODE KN4004A AUTO 52MM 1 EA
FUSE 5FVLB3152L FUSE GLASS TUBE 250V/50T 3.15A 1 EA
HS1 3105797200 HEAT SHINK T17*W23*H22 1 EA
IC1 1L7812CV-- IC REGULATOR L7812CV 1 EA
IC2 1L7805CV-- IC REGULATOR L7805CV 1 EA
L1 52C1374001 COIL 130UF 3A 1 EA
PCB 3104396142 PCB POWER 110*80*1.6T(96) 1 EA
PT1 1TLP560J-- IC PHOTO COUPLER TLP 560J 1 EA
R1 RD-4K102J- R CARBON FILM 1/4 1K OHM J 1 EA
R2 RD-4K103J- R CARBON FILM 1/4 10K OHM J 1 EA
R3 RD-4K562J- R CARBON FILM 1/4 5.6K OHM J 1 EA
R4 RD-2K102J- RESISTOR 1/2W - 1K OHM J 1 EA
R5 RD-4K101J- R CARBON FILM 1/4 100 OHM J 1 EA
R6 RD-4K102J- R CARBON FILM 1/4 1K OHM J 1 EA
R7 RS01F121J- R M-OXIDE FILM 1W 120 OHM J 1 EA
RL1 3119300100 RELAY PCF112D1M 250V 25/20A 1 EA
RL4 5SC0101404 SW RELAY OJ-SS-112LM 1C 1P 1 EA
T1 TSM3JZ47-- TRIAC SM3JZ47 1 EA
TR1 TKRC102M-- TR KRC 102-M (TAPPING) 1 EA
VAR D15G561K-- VARISTOR 15G561K/350V 1 EA
◆
DSA-185L, 185P PART LIST (Power PCB Assy)
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
