74
◆INDOOR UNIT PART LIST; DSA-095L
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100400301 BODY 1 HIPS T2.0
2 3108008700 MOTOR IDU 1 YDK-8-4A
3 3101500400 CUSHION MOTOR 2 CR ø30
4 3106400400 BEARING PLASTIC Ass`y 1
5 3100053700 FAN CROSS FLOW Ass`y 1 ø90.0 x L540
6 7485401012 SET SCREW 1 6S-4x10-E MFZN
7 3103002601 HOLDER MOTOR 1 HIPS T2.0
8 3110050800 EVAPORATOR Ass`y 1
9 3102501220 GUIDE EVA. 1 PVC L536xT0.7
10 3100603800 BRACKET PIPE 1 HIPS T2.0
11 3108100801 PAN DRAIN 1 HIPS T2.0
12 3106001600 BLADE VERTICAL 3 P.P. T1.5
13 3108003900 MOTOR STEPPING 1 MP24GA , GSP-24SW-061
14 3107600400 FLAP 1 HIPS T2.5
15 3101404800 COVER WIRE L 1 HIPS
16 3101404900 COVER WIRE R 1 HIPS
17 3100054202 LED PCB Ass`y 1
18 3100901600 CAP RUBBER 1 SILICON
19 3110050900 CONTROL BOX Ass`y 1
19-1 3100508400 CONTROL BOX 1 P.P. + G.F. 20%
19-2 3110051000 CONTROL PCB Ass`y 1
19-3 3108914100 TERMINAL BLOCK 1 JXO-CH-3P
19-4 3104896300 SENSOR ID Ass`y 1 PTM-KD-43C-D2
19-5 3101300100 POWER CORD Ass`y 1 16A 250V
19-6 3101203000 CLAMP WIRE 1 P.P. + G.F. 20%
20 3100400410 BODY-TOP 1 HIPS T2.0
21 3102200800 FRAME GRILLE 1 HIPS T2.5
22 3104508700 PLATE LED 1 P.C. Sheet T2.0
23 3104510200 PLATE SWITCH 1 P.C. Sheet T2.0
24 3101404600 COVER TERMINAL BLOCK 1 HIPS T2.0
25 3101100400 CASE FILTER 2 P.P. T2.0
26 3101902510 FILTER CARBON Ass`y 1 Black
27 3101902610 FILTER ELECTRO Ass`y 1 White
28 3102200900 FILTER FRAME 2 P.P. T2.0
29 3102402200 INSERT GRILLE 1 HIPS T2.5
30 3101403900 COVER LED 1 ABS T2.0
31 3104507200 PLATE MOUNTING 1 SBHG 1 T0.7
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
