◆INDOOR UNIT PART LIST; DSA-125L, 125P
No PART CODE PART NAME Q'TY SPEC REMARK
1 3110400301 BODY 1 HIPS T2.0
2 3118003500 MOTOR IDU 1 RB13B(220V, 50/60V)
3 3106400400 BEARING PLASTIC Ass`y 1
4 3110046000 FAN CROSS FLOW Ass`y 1 SAN+G.F 30% ø100xL615
5 7485401012 SET SCREW 1 6S-4x10-E MFZN
6 3113000400 HOLDER MOTOR L 1 HIPS T2.0
7 3113000500 HOLDER MOTOR R 1 HIPS T2.0
8 3114503300 PLATE EVAP. L 1 T2.0(GY176A)
9 3110054100 EVAPORATOR Ass`y 1
10 3112500900 GUIDE EVAP. U 1 PVC L623 x T1.0
11 3110603100 BRACKET PIPE 1 HIPS T2.0
12 3118100501 PAN DRAIN 1 HIPS T2.0
13 3116501001 BLADE VERTICAL 3 P.P T1.5
14 3117600101 FLAP 1 HIPS T2.5
15 3108003910 MOTOR STEPPING 1 MP24GA
16 3103210010 HOSE DRAIN Ass`y 1
17 3104301700 LED PCB Ass`y 1
18 3110063610 CONTROL BOX Ass`y 1
18-1 3110504000 CONTROL BOX 1 HIPS T2.0
18-2 3114208600 CONTROL PCB Ass`y 1
18-3 3118900200 TERMINAL BLOCK 1 JXO-CH-2P
18-4 3111200800 CLAMP WIRE 1 HIPS T2.0
18-5 3101301700 POWER CORD Ass`y 1 250V 15A
18-6 3114503900 PLATE EARTH 1 SGCC T1.0
18-7 3104896300 SENSOR ID Ass`y 1 PTM-KD-43C-D2
19 3110400200 BODY TOP 1 HIPS T2.0
20 3112200700 FRAME GRILLE 1 HIPS T2.5
21 3114504200 PLATE LED 1 PC SHEET T0.2
22 3103401400 KNOB SWITCH 1
23 3111403400 COVER TERMINAL BLOCK 1 HIPS T2.0
24 3101100400 CASE FILTER 2
25 3101902510 FILTER CARBON Ass`y 1 BLACK
26 3113700200 DUST COLLECTOR 1 NAC-001 DSA-125P
26-1 3101902610 FILTER ELECTRO Ass`y 1 DSA-125L
27 3111901400 FILTER FRAME 2 P.P T2.0
28 3112401900 GRILLE INSERT 1 HIPS T2.5
29 3111403700 COVER LED 1 ABS T2.0
30 3114503800 PLATE MOUNTING 1 SGCC T0.7
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
