◆INDOOR UNIT PART LIST; DSA-185L, 185P
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100400101 BODY 1 HIPS
2 3107600100 FLAP TOP 1 HIPS
3 3107600200 FLAP UNDER 1 HIPS
4 3106500401 BLADE VERTICAL 16 PP (GY171A)
5 3103000500 HOLDER MOTOR R 1 HIPS
6 3103000600 HOLDER MOTOR L 1 HIPS
7 3103000700 HOLDER BEARING 1 HIPS
8 3106400100 BEARING PLASTIC Ass`y 1 RUBBER I.D.ø6.0
9 3101800200 FAN CROSS FLOW Ass`y 1 O.D.ø100xL814
10 3100900100 CAP FRAME 3 HIPS
11 3108000310 MOTOR IDU 1 YDK-20-4A
12 3112400400 GRILLE INSERT 1 HIPS
13 3100506900 CONTROL BOX 1 HIPS
14 3107400010 EVAPORATOR Ass`y 1
15 3101940000 FILTER CARBON Ass`y 1 Black
16 3113700200 DUST COLLECTOR 1 NAC-001 DSA-185P
16-1 3101930000 FILTER ELECTRO Ass`y 1 DSA-185L
17 3101403700 COVER TERMINAL BLOCK 1 HIPS
18 3108120020 PAN DRAIN Ass`y 1 HIPS
19 3102210020 FRAME GRILLE Ass`y 1 HIPS
20 310191000C FILTER PRE R Ass`y 1 P.P. Black
21 310192000C FILTER PRE L Ass`y 1 P.P. Black
22 3102900500 HINGE R 1 POM
23 3102900600 HINGE L 1 POM
24 3114308700 CONTROL PCB Ass`y 1
25 3114305500 POWER PCB Ass`y 1
26 3108004300 STEPPING MOTOR 1 DC12V 400mm
27 3108004300 STEPPING MOTOR 1 DC12V 400mm
28 3104300401 LED PCB Ass`y 1
29 3108004310 PLATE EVA. L 1 SGCC T1.0
30 3107800200 LINK VER 1 POM
31 3107800100 LINK VER CAM 1 POM
32 3104300301 SWITCH PCB Ass`y 1 POM
33 31045003000 PLATE MOUNTING 1 SGCC T0.8
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
