80
◆INDOOR UNIT PART LIST; DSA-245L, 245P
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100400600 BODY 1
2 3108007510 MOTOR IDU 1 IC-9430DWKF7A
3 3101500400 CUSHION MOTOR 2 CR I.D30
4 3106400200 BEARING PLASTIC Ass`y 1 O.D37.0*I.D6.0
5 3100076400 FAN CROSS FLOW Ass`y 1 OD 100*L864
6 7485401012 SET SCREW 1 6S-4*10-E
7 3103003800 HOLDER MOTOR L/B 1 ABS T2.5
8 3103003900 HOLDER MOTOR R 1 ABS T2.5
9 3103004000 HOLDER BEARING 1 ABS T2.5
10 311009AC01 EVAPORATOR Ass`y 1
11 3102501400 GUIDE EVAP. 1 PVC
12 3108101400 PAN DRAIN 1 HI-PS
13 3106502700 BLADE VERTICAL M 3 PP
14 3107600500 FLAP UP 1 HI-PS
15 3107600600 FLAP DOWN 1 HI-PS
16 3107801700 LINK FLAP 1 HI-PS
17 3100702000 BUSHING 2 HI-PS
18 3103200800 HOSE DRAIN Ass`y 1
19 3108007600 MOTOR STEPPING 1 GSP-24RW-062
20 3104301700 LED PCB Ass`y 1
21 3100077060 CONTROL BOX Ass`y 1
21-1 3100510700 BOX CONTROL 1
21-2 3104308800 CONTROL PCB Ass`y 1
21-3 3108914100 TERMINAL BOLCK 1 JXO-CH-3P
21-4 3101300440 POWER CORD Ass`y 1 SJT 3X14 AWG105
21-5 3101200400 CLAMP CORD 1 DA-5N
21-6 3104897010 SENSOR ID Ass`y 1 PTM-KD43C-D2
21-7 5EPV050120 TRANSFORMER 1 DWA-220B
21-8 3106902400 CAPACITOR MOLD 1 2.0UF 400V
21-9 2150013200 AL FOIL EMI 1 AL100P(W100XL100)
22 3100400700 BODY TOP 1 HI-PS
23 3102201400 FRAME GRILLE 1 HI-PS
24 3104512400 PLATE LED 1 PC SHEET T0.2
25 3104510200 PLATE SWITCH 1 PC SHEET T0.2
26 3103401400 KNOB SWITCH 1 HI-PS
27 3100094300 FILTER CARBON Ass`y 1 Black
28 3113700500 DUST COLLECTOR 1 NAC-002 DSA-245P
28-1 3100094400 FILTER ELECTRO Ass`y 1 DSA-245L
29 3101406820 COVER TERMINAL BLOCK 1 HI-PS
30 3102201500 FILTER FRAME 2 PP
31 3102403500 GRILLE INSERT 1 ABS
32 3101406900 COVER LED 1
33 3104512600 PLATE INSERT GRILLE 1 PET T0.1
34 3104511800 PLATE MOUNTING 1 SBHG 1 T0.7
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
To Next Page
