◆OUTDOOR UNIT PART LIST; DSA-095L
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100014720 PAN BASE Ass`y 1 SECC T1.2
2 3106000900 COMP. BOLT 3 M8 x L46.5
3 3102100800 FOOT 1 SECC T1.2
4 3108104AE0 COMP. GROMMET 3 EPDM
5 3117104470 COMPRESSOR Ass`y 1 QK125K** LG
6 7400208411 COMP. WASHER 3 M8.4 x 22 x T1.6
7 7392801211 COMP. NUT 3 M8xP1.25 MFZN
8 3110046200 CONDENSER Ass`y 1 L465xW208.5xH508
9 3114434400 PIPE COND IN 1 C1220T
10 3114433700 PIPE COND OUT 1 C1220T
11 3100602200 BRACKET SERVICE 1 SECC T1.2
12 3115401900 SERVICE VALVE 1 3/8" (GAS)
13 3105400802 SERVICE VALVE 1 1/4" (LIQUID)
14 7347602011 BOLT HEX 4 M6x20 MFZN
15 3110048000 PIPE SUCTION Ass`y 1 C1220T
16 3110048300 PIPE DISCHARGE Ass`y 1 C1220T
17 3114424300 PIPE CAPILLARY Ass`y 1 ID ø1.6 x L1,200
18 3102501100 GUIDE SUPPORT 1 SECC T1.2
19 3102402600 GRILLE CONDENSER 1 P.E. 660x525.5xT3.5
20 3100601903 BRACKET MOTOR 1 SBHG1 T1.2
21 3118001100 MOTOR ODU 1 YDK-35-6A
22 3101801000 FAN PROPELLER 1 ABS+G.F20% (BLACK)
23 7400208411 WASHER PLAIN 1 PW-2-8 MFZN
24 7392800011 NUT LOCK 1 M8 x P1.25 MFZN
25 3114504110 PLATE PARTITION 1 SBHG1 T0.8
26 3104201900 PANEL CONTROL 1 SBHG1 T0.8
27 3108912300 TERMINAL BLOCK 1 SN-DBW-03P
28 3109502010 CAPACITOR DUAL 1 2.0+25µF 400VAC
29 3101201100 CLAMP CAPACITOR 1 SBHG1 T1.0
30 3101202000 CLAMP CORD 1 NYLON
31 3100801210 CABINET FRONT 1 SECC T0.8
32 3112402500 GRILLE DISCHAGE 1
33 3103510700 LABEL BRAND 1 P.C.FILM 346x90xT0.4
34 3100801300 CABINET SIDE 1 SECC T0.8
35 3104201800 PANEL TOP 1 SECC T0.8
36 3102600300 HANDLE 1 ABS
37 3102101000 FOOT CUSHION 4 NBR
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
