92
◆DSA-125L, 125P
No PART CODE PART NAME Q'TY SPEC REMARK
1 3110504000 CONTROL BOX 1 HIPS T2.0 (BLACK)
2 3101301700 POWER CORD 1 250V 15A
3 3114302020 CONTROL PCB ASS’Y1
4 3118900200 TERMINAL BLOCK 1 JXO-CH-2P
5 3108003910 STEPPING MOTOR 1 24BYJ-48-1
6 3112716100 HARNESS LED PCB 1 UL1007 8*26AWG
7 3112716250 HARNESS ID EARTH 1 UL1015 16AWG
8 3104896300 SENSOR ID ASS'Y 1 PTM-KD-43C-D2
9 3101200400 CLAMP CORD 1 DA-5N
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
