DISASSEMBLY AND REASSEMBLY
3.Separate the evaporator
from the indoor unit.
4
Evaporator
2.Separete the ass’y tray drain
from the body.
1.Push the left hook and
separate the left part out of
evaporator.
1.Separate the fan motor
from the fan.
No Parts Procedure Remark
2.Push the right hook and
separate the right part out
of evaporator.
5
Fan motor and
cross fan
1111
To Next Page
