No. Part Name Quantity Item Code
1. Air outlet grille 1 KFR35W.1.2-3(G1-1)
2 Fan screw nut 1 LD06-04
3 Left handle 1 KFR35W.1.2-4(G1-1)
4 Front panel 1 KFR35W.1.2-1(G1-1)
5 Outdoor fan 1 LF51W.1.5.2(G1-5)
6 Partition 1 KFR35W.1.6-1(G1-1)
7 Outdoor fan motor supporter 1 KFR35W.1.5.1-1(G1-1)
8 Power supply cord clip 1 SL01-04
9 Outdoor unit terminal block 1 DQ12-12
10 Electrical install board supporter 1 KFR35W.3-1(G1-1)
11 Compressor capacitor 1 DQ11-53
12 capacitor fixer 1 BJ06-03
13 Fan motor capacitor 1 DQ11-06
14 Condenser 1 KF51W.8.1(779)
15 Left back side board 1 KFR35W.1.8(G1-1)
16 Back cover 1 KFR35W.1.7(G1-1)
17 Top panel 1 KFR35W.1.1-1(G1-1)
18 Right back side board 1 KFR35W.1.3-1
19 Compressor 1 SHZ73LC4-U
20 Back board 1 KFR35W.1.4-1(G1-1)
21 Capillary 1 KF50W.8.2(D9-120)(236)
22 1/4 on-off valve 1 DG03-12
23 1/2 on-off valve 1 DG03-06
24 valve board 1 KF25W.9.1(B1-130)
25 Discharge pipe 1 KF50W.9.1(D9-120)(236)
26 Counter-flow windpipe 1 KF50W.9.1-3(D9-120)(236)
27 Outdoor fan motor 1 DQ01-54B
