Micom Power Supply (6)
DESCRIPTION
MICOM Power is supplied 5V at Number 42 using Digital, Number 22 using Reference of A/D Converter.
CE2 is Ripple filter and CC1 is Noise filter.
42
Vcc
5V
10µF/16V
CE2
CC1
104
22
21
MICOM
