56
DESCRIPTION
MICOM Power is supplied 5V at Number 42 using VDD, Number 19, 20 Vsing Oscillator, CC13 is noise filter.
Micom Power Supply(7)
VDD 42
CE5
10µF
16V
CC11
104
CC13
104
+
5V
41
40
39
22
21
19
OSC
8MHz
20
VSS
MICOM
