Daewoo DTC-14 User Manual

Inch Different Parts List
LOC INCH PART CODE PART NAME PART DESCRIPTION REMARK
C304
14 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
20 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
21 CEXF1H100V C ELECTRO 50V RSS 22MF (5X11) TP
C401
14 CMYE2D334J C MYLAR 200V PU 0.33MF J
20 CMYE2D434J C MYLAR 200V PU 0.43MF J
21 CMYE2D394J C MYLAR 200V PU 0.39MF J
C404
14 CMYH3C692J C MYLAR 1.6KV BUP 6900PF J
20 CMYH3C692J C MYLAR 1.6KV BUP 6900PF J
21 CMYH3C722H C MYLAR 1.6KV BUP 7200PF H
C405
14
- - -
20
- - -
21 CCXB3D271K C CERA 2KV B 270PF K (T)
J008
14 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
20 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
21
- - -
L402
14
- - -
20
- - -
21 58H0000055 COIL H-LINEARITY TRL-361A
P401
14 4859240020 CONN WAFER YFW500-05
20 4859240020 CONN WAFER YFW500-05
21 4859240120 CONN WAFER YFW500-05
R401
14 - - -
20 - - -
21 RN02B222JS R METAL FILM 2W 2.2K OHM J SMALL
R404
14 - - -
20 - - -
21 RN02B222JS R METAL FILM 2W 2.2K OHM J SMALL
R808
14 RS02Z159JS R M-OXIDE FILM 2W 1.5K OHM J SMALL
20 RS02Z159JS R M-OXIDE FILM 2W 1.5K OHM J SMALL
21 RS02Z109JS R M-OXIDE FILM 2W 1K OHM J SMALL
RC301
14 HRFT471JCA R CHIP 1/10 470 OHM J 2012
20 HRFT431JCA R CHIP 1/10 430 OHM J 2012
21 HRFT621JCA R CHIP 1/10 620 OHM J 2012
RC304
14 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
20 HRFT242JCA R CHIP 1/10 2.4K OHM J 2012
21 HRFT302JCA R CHIP 1/10 3K OHM J 2012
RC405
14 HRFT392JCA R CHIP 1/10 3.9K OHM J 2012
20 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
21 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RC406
14 - - -
20 - - -
21 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
SCT1
14 4859303430 SOCKET CRT PCS633A
20 4859303430 SOCKET CRT PCS633A
21 4859303530 SOCKET CRT PCS629-03C
V01
14 58D0000082 COIL DY ODY-M1489
20 58D0000083 COIL DY ODY-M2050
21 - - -
V901
14 48A96414P4 CRT BARE A34JLL90X (K)
20 48A96420P4 CRT BARE A48JLL90X
21 4859625560 CRT A51EFK155X01
Cabinet Parts List
LOC INCH PART CODE PART NAME PART DESCRIPTION REMARK
ZZ131
14 48519A4710 CRT GROUND NET 1401S-1015-1P
20 48519A5110 CRT GROUND NET 2001S-1015-1P
21 48519A5310 CRT GROUND NET 2101S-1015-1P
ZZ132
14 58G0000084 COIL DEGAUSSING DC-1450
20 58G0000086 COIL DEGAUSSING DC-2050
21 58G0000074 COIL DEGAUSSING DC-2070
MDL/PARTS COVER BACK A CRT AS MASK FRONT A PCB MAIN MANUAL BUTTON CTRL BUTTON POWER
DTC-14V1TM 48B3740A01 PTBCSHA605 PTRTPWA605 PTFMSJA605 PTMPMSA605 4851931802 4854939103
DTC-14V3TM 48B3740A01 PTBCSHA635 PTRTPWA605 PTFMSJA635 PTMPMSA605 4851931402 4854940103
DTC-14V4TM 48B3740A01 PTBCSHA605 PTRTPWA605 PTFMSJA636 PTMPMSA605 4851934002 4854940803
DTC-14V5TM 48B3740A01 PTBCSHA605 PTRTPWA605 PTFMSJA637 PTMPMSA605 4851934302 4854943503
DTC-14U1TM 48B3740A01 PTBCSHA638 PTRTPWA605 PTFMSJA638 PTMPMSA638 4851931602 4854942703
DTC-20V1TM 48B3740A01 PTBCSHD217 PTRTPWD217 PTFMSJD217 PTMPMSD217 4851932002 4854939503
DTC-20V3TM 48B3740A01 PTBCSHD336 PTRTPWD217 PTFMSJD336 PTMPMSD217 4851933502 4854940003
DTC-20V4TM 48B3740A01 PTBCSHD217 PTRTPWD217 PTFMSJD337 PTMPMSD217 4851934702 4854941303
DTC-20V5TM 48B3740A01 PTBCSHD217 PTRTPWD217 PTFMSJD338 PTMPMSD217 4851933902 4854942403
DTC-20U1TM 48B3740A01 PTBCSHD217 PTRTPWD217 PTFMSJD343 PTMPMSD343 4851934202 4854943303
DTC-21V1TM 48B3740A01 PTBCSHD216 4859625560 PTFMSJD216 PTMPMSD216 4851932302 4854939403
DTC-21V3TM 48B3740A01 PTBCSHD339 4859625560 PTFMSJD339 PTMPMSD216 4851932502 4854940503
DTC-21V4TM 48B3740A01 PTBCSHD216 4859625560 PTFMSJD340 PTMPMSD216 4851930902 4854941403
DTC-21U1TM 48B3740A01 PTBCSHD344 4859625560 PTFMSJD344 PTMPMSD344 4851937302 4854943003
DTC-21U3TM 48B3740A01 PTBCSHD345 4859625560 PTFMSJD345 PTMPMSD345 4851933802 4854943003
REMOCON
