RC304 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012 14"
RC306 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC307 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC308 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC309 HRFT154JCA R CHIP 1/10 150K OHM J 2012
RC310 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC313 HRFT224JCA R CHIP 1/10 220K OHM J 2012
RC404 HRFT561JCA R CHIP 1/10 560 OHM J 2012
RC405 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012 21"
RC405 HRFT392JCA R CHIP 1/10 3.9K OHM J 2012 20"
RC405 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012 14"
RC406 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012 Only 21"
RC408 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC419 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RC420 HRFT394JCA R CHIP 1/10 390K OHM J 2012
RC501 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC503 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC504 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC505 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC506 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC507 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC508 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC509 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC510 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC511 HRFT470JCA R CHIP 1/10 47 OHM J 2012
RC512 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RC513 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC514 HRFT151JCA R CHIP 1/10 150 OHM J 2012
RC515 HRFT000-CA R CHIP 1/10 0 OHM 2012
RC516 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC517 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC518 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC519 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC520 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC521 HRFT363JCA R CHIP 1/10 36K OHM J 2012
RC522 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC523 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RC524 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC526 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RC527 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC528 HRFT221JCA R CHIP 1/10 220 OHM J 2012
RC529 HRFT271JCA R CHIP 1/10 270 OHM J 2012
RC530 HRFT271JCA R CHIP 1/10 270 OHM J 2012
RC531 HRFT271JCA R CHIP 1/10 270 OHM J 2012
RC532 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC534 HRFT334JCA R CHIP 1/10 330K OHM J 2012
RC535 HRFT184JCA R CHIP 1/10 180K OHM J 2012
RC537 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC538 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RC539 HRFT561JCA R CHIP 1/10 560 OHM J 2012
RC541 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC542 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC543 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC553 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC555 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC560 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
LOC PART CODE PART NAME PART DESCRIPTION REMARK
RC605 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RC606 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RC607 HRFT753JCA R CHIP 1/10 75K OHM J 2012
RC610 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC611 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RC620 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC621 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC623 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RC630 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC702 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC703 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC704 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC705 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC706 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC707 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC708 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC709 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC710 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC711 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC712 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC713 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC714 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC715 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RC716 HRFT392JCA R CHIP 1/10 3.9K OHM J 2012
RC717 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC719 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC720 HRFT271JCA R CHIP 1/10 270 OHM J 2012
RC721 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC722 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC723 HRFT624JCA R CHIP 1/10 620K OHM J 2012
RC725 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC726 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC727 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC729 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC730 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC733 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC736 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC738 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC751 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC752 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC754 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC755 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC822 HRFT363JCA R CHIP 1/10 36K OHM J 2012
RC828 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC829 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC901 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC902 HRFT302JCA R CHIP 1/10 3K OHM J 2012
RC903 HRFT302JCA R CHIP 1/10 3K OHM J 2012
RC904 HRFT302JCA R CHIP 1/10 3K OHM J 2012
RC905 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC906 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC907 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
SCT1 4859303530 SOCKET CRT PCS629-03C PHILIPS
SCT1 4859303430 SOCKET CRT PCS633A ORION
SCT1 4859303430 SOCKET CRT PCS633A CPT
SF101 5PK7257M-- FILTER SAW K7257M
LOC PART CODE PART NAME PART DESCRIPTION REMARK
SF102 5PK9652M-- FILTER SAW K9652M
SJ01 4859110750 JACK PIN BOARD PH-JB-9707A
SJ02 4859109950 JACK PIN BOARD PH-JB-9710A
SW701 5S50101090 SW TACT SKHV17910A
SW702 5S50101090 SW TACT SKHV17910A
SW703 5S50101090 SW TACT SKHV17910A
SW704 5S50101090 SW TACT SKHV17910A
SW705 5S50101090 SW TACT SKHV17910A
SW801 5S40101146 SW POWER PUSH SS-160-7-B
T401 50D10A3--- TRANS DRIVE TD-10A3
T402 50H0000198 FBT FSA37012M
T801 50M4242B4- TRANS SMPS TSM-4242B4
U101 4859719930 TUNER VARACTOR DT5-BF18D
X501 5XEX4R433B CRYSTAL QUARTZ HC-49U 4.43361M 15PPM
TP
X502 5XEX3R579B CRYSTAL QUARTZ HC-49U 3.57954M 15PPM
TP
X701 5XEX4R000C CRYSTAL QUARTZ HC-49U 4.0000MHZ (TP)
LOC PART CODE PART NAME PART DESCRIPTION REMARK
®
®
