Daewoo DTC-14 User Manual

CC534 HCFK334ZCA C CHIP CERA 50V Y5V 0.33MF Z 2012
CC612 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC613 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012
CC701 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC702 HCQK300JCA C CHIP CERA 50V CH 30PF J 2012
CC703 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012
CC705 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC707 HCQK820JCA C CHIP CERA 50V CH 82PF J 2012
CC708 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC709 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC722 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC723 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC724 HCQK560JCA C CHIP CERA 50V CH 56PF J 2012
D101 D1N4148--- DIODE 1N4148 (TAPPING)
D103 D1SS85TA-- DIODE 1SS85TA
D105 DUZ33B---- DIODE ZENER UZ-33B
D106 D1N4148--- DIODE 1N4148 (TAPPING)
D107 DMTZJ5R1A- DIODE ZENER MTZJ 5.1A (TAPPING)
D108 D1SS85TA-- DIODE 1SS85TA
D301 D1N4937G-- DIODE 1N4937G
D303 D1N4937G-- DIODE 1N4937G
D304 DBZX55C62- DIODE ZENER BZX55C62
D402 D1N4937G-- DIODE 1N4937G
D403 D1N4937G-- DIODE 1N4937G
D404 DDG3------ DIODE DG3
D410 DMTZJ5R1A- DIODE ZENER MTZJ 5.1A (TAPPING)
D450 D1N4148--- DIODE 1N4148 (TAPPING)
D452 D1N4148--- DIODE 1N4148 (TAPPING)
D506 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
D508 D1N4148--- DIODE 1N4148 (TAPPING)
D509 D1N4148--- DIODE 1N4148 (TAPPING)
D510 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
D512 D1N4148--- DIODE 1N4148 (TAPPING)
D513 D1N4148--- DIODE 1N4148 (TAPPING)
D514 D1N4148--- DIODE 1N4148 (TAPPING)
D601 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
D603 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
D604 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
D620 D1N4148--- DIODE 1N4148 (TAPPING)
D701 DUZ3R9B--- DIODE ZENER UZ-3.9B
D703 DMTZJ5R1A- DIODE ZENER MTZJ 5.1A (TAPPING)
D706 DLH2PR---- LED BLOCK LH-2P-R
D720 D1N4148--- DIODE 1N4148 (TAPPING)
D806 DRGP30J--- DIODE RGP30J
D808 DRGP15J--- DIODE RGP15J
D810 D1N4936GP- DIODE 1N4936GP (TAPPING)
D812 D1N4936GP- DIODE 1N4936GP (TAPPING)
D816 DUZ10BL--- DIODE ZENER UZ-10BL
D837 DLT2A05G-- DIODE LT2A05G (TP)
D838 DLT2A05G-- DIODE LT2A05G (TP)
D839 DLT2A05G-- DIODE LT2A05G (TP)
D840 DLT2A05G-- DIODE LT2A05G (TP)
D841 DRZ1155V1- DIODE ZENER RZ1155V1
F801 5FSGB4022L FUSE GLASS TUBE SEMKO TL 4A 250V MF51
F801A 4857415001 CLIP FUSE PFC5000-0702
LOC PART CODE PART NAME PART DESCRIPTION REMARK
F801B 4857415001 CLIP FUSE PFC5000-0702
I301 PTA2SW7104 HEAT SINK ASS`Y 1TDA1771-- + 7174301011
I301 1TDA1771-- IC VERTICAL TDA1771
I301A 4857027104 HEAT SINK SPCC T1.0+SN
I301B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I501 1STV2238DQ IC CHIP VIDEO STV2238D
I601 1TDA7267A- IC AMP TDA7267A
I601A 4857031500 HEAT SINK SPCC+SN T1.0
I602 1TDA7267A- IC AMP TDA7267A Only U
I701 1ST195EPMQ IC CHIP MICOM OTP ST92T195Q1/EPM
I702 1AT24C16PC IC AT24C16-10PC
I703 1KA7805--- IC REGULATOR KA7805
I704 1KRT30---- IC PREAMP KRT30
I801 4850M04710 MODULE POWER DPM001T1A
I805 PTA2SW6904 HEAT SINK ASS`Y 1STV8131-- + 7174301011
I805 1STV8131-- IC REGULATOR STV8131
I805A 4857026904 HEAT SINK AL EX
I805B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I901 PTB3SW1100 HEAT SINK ASS`Y 1TDA6103Q- + 7174301011
I901 1TDA6103Q- IC VIDEO TDA6103Q
I901A 4857031100 HEAT SINK A1050P-H24 T2.0
I901B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
JC001 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC002 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC003 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC004 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC005 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC006 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC007 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC008 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC009 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC010 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC011 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC012 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC013 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC014 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC015 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC016 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC017 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC018 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC019 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC020 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC021 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC022 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC023 HRFT000-CA R CHIP 1/10 0 OHM 2012
L101 58N0000044 COIL VCO TRF-V010
L402 58H0000055 COIL H-LINEARITY TRL-361A 14", 20",
21"
L511 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L701 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L702 5CPZ569K04 COIL PEAKING 5.6UH K (AXIAL 10.5MM)
L800 58Q0000093 COIL DELAY LINE RS208
L801 5PLF24A4-- FILTER LINE LF-24A4
L802 5MC0000100 COIL BEAD HC-3550
L803 5MC0000100 COIL BEAD HC-3550
LOC PART CODE PART NAME PART DESCRIPTION REMARK
L805 58CX430599 COIL CHOKE AZ-9004Y 940K TP
L806 5CPZ100K04 COIL PEAKING 10UH 10.5MM K (LAL04TB)
P101 485923162S CONN WAFER YW025-03 (STICK)
P401 4859240120 CONN WAFER YFW500-06
P401 4859240020 CONN WAFER YFW500-05
P401 4859240020 CONN WAFER YFW500-05
P601 485923162S CONN WAFER YW025-03 (STICK)
P602 485923162S CONN WAFER YW025-03 (STICK)
P901 4850709N02 CONNECTOR YBNH250-
09YBNT025+ULW=300
PWC1 PTWASW2910 CORD POWER ASS`Y 4859901111+ HOUSING
Q101 TKTC3198Y- TR KTC3198Y
Q105 TKTC3198Y- TR KTC3198Y
Q401 TKTC3207-- TR KTC3207 (TP)
Q402 T2SD2499-- TR 2SD2499
Q503 TKTA1266Y- TR KTA1266Y (TP)
Q505 TKTA1266Y- TR KTA1266Y (TP)
Q506 TKTA1266Y- TR KTA1266Y (TP)
Q601 TKTC3198Y- TR KTC3198Y
Q620 TKTA1266Y- TR KTA1266Y (TP)
Q701 TKTA1266Y- TR KTA1266Y (TP)
Q702 TKTC3198Y- TR KTC3198Y
Q703 TKTC3198Y- TR KTC3198Y
Q705 TKTC3198Y- TR KTC3198Y
Q710 TKTC3198Y- TR KTC3198Y
Q801 PTA2SW7611 HEAT SINK ASS`Y T2SK2677-- + 7174301211
Q801 T2SK2677-- FET 2SK2677
Q801A 4857027611 HEAT SINK AL EX BK
Q801B 7174301211 SCREW TAPPTITE TT2 RND 3X12 MFZN
Q802 TKSA1013Y- TR KSA1013Y (TP)
R101 RD-4Z242J- R CARBON FILM 1/4 2.4K OHM J
R102 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R103 RD-4Z432J- R CARBON FILM 1/4 4.3K OHM J
R109 RD-4Z183J- R CARBON FILM 1/4 18K OHM J
R110 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R111 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R120 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R301 RD-2Z249J- R CARBON FILM 1/2 2.4 OHM J
R302 RN01B229JS R METAL FILM 1W 2.2 OHM J SMALL
R303 RN02B271JS R METAL FILM 2W 270 OHM J SMALL
R307 RN02B910JS R METAL FILM 2W 91 OHM J SMALL
R308 RN02B910JS R METAL FILM 2W 91 OHM J SMALL
R309 RN02B910JS R METAL FILM 2W 91 OHM J SMALL
R310 RN02B910JS R METAL FILM 2W 91 OHM J SMALL
R312 RN01B479JS R METAL FILM 1W 4.7 OHM J SMALL
R401 RN02B222JS R METAL FILM 2W 2.2K OHM J SMALL
R402 RS02Z103JS R M-OXIDE FILM 2W 10K OHM J SMALL
R403 RS01Z479J- R M-OXIDE FILM 1W 4.7 OHM J (TAPPING)
R404 RN02B222JS R METAL FILM 2W 2.2K OHM J SMALL
R406 RD-2Z472J- R CARBON FILM 1/2 4.7K OHM J
R407 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R408 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R409 RD-4Z561J- R CARBON FILM 1/4 560 OHM J
R410 RN01B132JS R METAL FILM 1W 1.3K OHM J SMALL
R501 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
LOC PART CODE PART NAME PART DESCRIPTION REMARK
R502 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R503 RN01B300JS R METAL FILM 1W 30 OHM J SMALL
R504 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R512 RD-4Z750J- R CARBON FILM 1/4 75 OHM J
R525 RD-4Z104J- R CARBON FILM 1/4 100K OHM J
R532 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R601 RD-2Z271J- R CARBON FILM 1/2 270 OHM J
R611 RD-4Z362J- R CARBON FILM 1/4 3.6K OHM J
R612 RD-4Z511J- R CARBON FILM 1/4 510 OHM J
R613 RN02B129JS R METAL FILM 2W 1.2 OHM J SMALL
R614 RN02B129JS R METAL FILM 2W 1.2 OHM J SMALL
R615 RN02B182JS R METAL FILM 2W 1.8K OHM J SMALL
R715 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R723 RD-4Z332J- R CARBON FILM 1/4 3.3K OHM J
R735 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R736 RD-4Z224J- R CARBON FILM 1/4 220K OHM J
R753 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R801 DEC140M290 POSISTOR ECPCC140M290
R802 RX10B339JN R CEMENT 10W 3.3 OHM J BENCH 4P
R803 RD-4Z394J- R CARBON FILM 1/4 390K OHM J
R804 RD-4Z394J- R CARBON FILM 1/4 390K OHM J
R805 RS02Z129JS R M-OXIDE FILM 2W 1.2 OHM J SMALL
R806 RD-4Z363J- R CARBON FILM 1/4 36K OHM J
R807 RD-4Z561J- R CARBON FILM 1/4 560 OHM J
R808 RS02Z109JS R M-OXIDE FILM 2W 1 OHM J SMALL 21"
R808 RS02Z159JS R M-OXIDE FILM 2W 1.5 OHM J SMALL 20"
R808 RS02Z159JS R M-OXIDE FILM 2W 1.5 OHM J SMALL 14"
R809 RD-4Z363J- R CARBON FILM 1/4 36K OHM J
R810 RD-4Z623J- R CARBON FILM 1/4 62K OHM J
R812 RC-2Z825KP R CARBON COMP 1/2 8.2M OHM K
R819 RS02Z278JS R M-OXIDE FILM 2W 0.27 OHM J SMALL
R823 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R824 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R834 RD-4Z392J- R CARBON FILM 1/4 3.9K OHM J
R850 RN02B180JS R METAL FILM 2W 18 OHM J SMALL
R901 RN01B124JS R METAL FILM 1W 120K OHM J SMALL
R902 RN01B124JS R METAL FILM 1W 120K OHM J SMALL
R903 RN01B124JS R METAL FILM 1W 120K OHM J SMALL
R910 RD-2Z152J- R CARBON FILM 1/2 1.5K OHM J
R911 RD-2Z152J- R CARBON FILM 1/2 1.5K OHM J
R912 RD-2Z152J- R CARBON FILM 1/2 1.5K OHM J
RC101 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RC106 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC107 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC111 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RC114 HRFT432JCA R CHIP 1/10 4.3K OHM J 2012
RC115 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC118 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC301 HRFT621JCA R CHIP 1/10 620 OHM J 2012 21"
RC301 HRFT431JCA R CHIP 1/10 430 OHM J 2012 20"
RC301 HRFT471JCA R CHIP 1/10 470 OHM J 2012 14"
RC302 HRFT242JCA R CHIP 1/10 2.4K OHM J 2012
RC303 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC304 HRFT302JCA R CHIP 1/10 3K OHM J 2012 21"
RC304 HRFT242JCA R CHIP 1/10 2.4K OHM J 2012 20"
LOC PART CODE PART NAME PART DESCRIPTION REMARK
®
®
®
®
®
®
®
