ZZ100 48B5552C03 TRANSMITTER REMOCON R-52C03 (AAA)
ZZ110 PTACPWE102 ACCESSORY AS DDT-21H9ZTF
00010 4850Q00910 BATTERY R03/NN
ZZ120 PTBCSHE102 COVER BACK AS DDT-21H9ZTF
M211 4852161301 COVER BACK HIPS GY 21H9
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
M781 4857817630 CLOTH BLACK FELT 400X20X0.7
ZZ130 PTPKCPE102 PACKING AS DDT-21H9ZTF
10 6520010100 STAPLE PIN AUTO W65
M801 4858061200 BOX CARTON DW-3 21H9
M811 4858199500 PAD EPS 21H9
M821 4858219101 BAG P.E P.E FOAM T0.5X1300X1150
ZZ131 48519A7110 CRT GROUND NET 2101F-1015-1P
ZZ132 58G0000154 COIL DEGAUSSING DC-21F1
ZZ140 PTCACAE102 CABINET AS DDT-21H9ZTF
M111 4851115200 PANEL CONTROL ASSY 23285+49520+55463+48618
M201A 4856017303 SCREW CRT FIX 5X30 L80 BK
M201B 4856017310 SCREW CRT FIX 5X30 L190 BK
M201C 4856215401 WASHER RUBBER CR T1.0
M211A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M211B 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M281 4852823903 DOOR CD HIPS GY
M281A 4855800018 LABEL(BADGE DVD) NI+CR
M352 4853535500 HOLDER AC CORD NYLON 66
M381 4853818500 FRAME POWER FR HIPS BK 21H9
M381A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M561 48556175SD MARK BRAND SILVER DIA-CUTTING
M671 4856716000 SPRING SWPA PIE0.5
SP601 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
SP602 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
V901 PTRTPWD572 CRT AS DDT-21H9ZZF
PA401 4850704N07 CONNECTOR SE100J+172792+USW=500
V901 4859637360 CRT A51ERF135X80
ZZ200 PTFMSJE102 MASK FRONT AS DDT-21H9ZTF
M201 4852080501 MASK FRONT HIPS GY 21H9
ZZ202 PTSPPWE102 SPEAKER AS DDT-21H9ZTF
PA601 4850704S31 CONNECTOR YH025-04+YRT205+ULW800400
SP01 4858313510 SPEAKER SP-50110F05
SP02 4858313510 SPEAKER SP-50110F05
ZZ290 PTMPMSE102 PCB MAIN MANUAL AS DDT-21H9ZTF
10 2193102005 SOLDER BAR SN:PB=63:37 S63S-1320
30 2291050616 FLUX SOLDER JS-64T3
40 2291050301 FLUX SOLVENT IM-1000
C402 CMYH3C602J C MYLAR 1.6KV BUP 6000PF J
C408 CMYE2D304J C MYLAR 200V PU 0.3MF J
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C802 CH1BFE472M C CERA AC AC400V 4700PF M U/C/V
C805 CEYD2G181D C ELECTRO 400V FHS 180MF (25X35)
C810 CCYR3D102K C CERA 2KV R 1000PF K 125 DE1207
C814 CEYF2D101V C ELECTRO 200V RSS 100MF (16X31.5)
C830 CEYF2D101V C ELECTRO 200V RSS 100MF (16X31.5)
D406 DDG3——— DIODE DG3
D750 DLH3PRG—- LED BLOCK LH-3P-RG
D751 DLH3PRG—- LED BLOCK LH-3P-RG
D810 DRGP30J—- DIODE RGP30J DO-201AD 600V 3A
D814 DD3S6M2004 DIODE D3S6MP2004
D815 DRGP30J—- DIODE RGP30J DO-201AD 600V 3A
D820 DD3S6M2004 DIODE D3S6MP2004
I301 PTF2SW7910 HEAT SINK ASS`Y 1TDA8357J- + 7174300811
00001 1TDA8357J- IC VERTICAL TDA8357J
0000A 4857027910 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I502 124LC16B1B IC MEMORY 24LC16B1B
I601 PTE2SW4421 HEAT SINK ASS`Y 1TDA8944J- + 7174300811
00001 1TDA8944J- IC SOUND TDA8944J
0000A 4857024421 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I801 PTP2SW4600 HEAT SINK ASS’Y 1STRW6754- + 7174300811
LOC PART CODE PART NAME DESCRIPTION REMARK
00001 1STRW6754- IC POWER STR-W6754
0000A 4857024600 HEAT SINK AL EX B/K
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I802 1LTV817C— IC PHOTO COUPLER LTV-817C
I803 1K1A78R05A IC REGULATOR K1A78R05AP1 5.0V 1.0A TO-220
I804 PT22SW7800 HEAT SINK ASS`Y 1K1A78R05A + 7174300811
00001 1K1A78R05A IC REGULATOR K1A78R05AP1 5.0V 1.0A TO-220
0000A 4857027800 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I805 PT32SW7800 HEAT SINK ASS`Y 1K1A78R33A + 7174300811
00001 1K1A78R33A IC REGULATOR K1A78R33AP1 3.3V 1.0A TO-220
0000A 4857027800 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I806 1K78R12—- IC REGULATOR KIA78R12API
I807 1K78R08—- IC REGULATOR KIA78R08API
I809 1LD1117V50 IC REGULATOR LD1117AV50 5.0V 2% TO-220
I810 1DP142—— IC ERROR AMP DP142
I811 PTT2SW6902 HEAT SINK ASS`Y 1LD1117V33 + 7174300811
00001 1LD1117V33 IC REGULATOR LD1117AV33 3.3V 2% TO-220
0000A 4857026902 HEAT SINK AL EX BK
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I901 PTM1SW8902 HEAT SINK ASS`Y 1TDA6107AJ + 7174300811
00001 1TDA6107AJ IC VIDEO TDA6107AJF
0000A 4857018902 HEAT SINK A1050P-H24
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
ID02 1KA4558—- IC AMP KA4558
IQ01 1KRT30—— IC PREAMP KRT30
JPA01 4859200401 SOCKET RGB YRS21-R1
JPA04 4859111450 JACK PIN BOARD YSC03P-5120-L
L401 58C0000118 COIL CHOKE CH-191A
L403 58H0000076 COIL H-LINEARITY TRL-121B
LF801 5PLF24A3— FILTER LINE LF-24A3
M193 4850M09010 MODULE DVD LOADER DQL-2308-7D1TEN
M193A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M221 4852221700 CABINET BOTTOM FR HIPS BK 21H9
M221A 7178300811 SCREW TAPPTITE TT2 WAS 3X8 MFZN
M382 4853818901 FRAME DECK HIPS BK
M382A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M391 4853954000 BRKT EARTH C5212P-1/2M T0.2
M392 4853954000 BRKT EARTH C5212P-1/2M T0.2
M393 4853954000 BRKT EARTH C5212P-1/2M T0.2
M721 4857250100 SHIELD CASE ET T0.5
M722 4857251500 SHIELD BOTTOM ET T0.4
M722A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
P502 4859235520 CONN WAFER YW025-12
P802 4859242220 CONN WAFER YFW800-02
PA101 4850701V01 CONNECTOR RINGTERM4.3+USW=200
PA801 WP-1BK1515 WIRE LEAD 1007 AWG22 1/0.65 BK 5-150-5
PA901 4850704S04 CONNECTOR YH025-04+YST025+ULW=400
PA902 4850705S04 CONNECTOR YH025-05+YBNH250+ULW=400
PAD01 4859002960 CABLE FFC 1.0-K-19P-100MM 10X5-10X5 AL
PAD02 4859002860 CABLE FFC 1.0-K-15P-100MM 10X5-10X5 AL
PD01 4859297220 CONN WAFER GF102-19S-TS 19P ST
PD02 4859297120 CONN WAFER GF102-15S-TS 15P ST
PWC1 4859906210 CORD POWER AS LP-21R+H03VVH2+LOCK=2200
Q401 PTN2SW4500 HEAT SINK ASS`Y T2SD2578— + 7174300811
00001 T2SD2578— TR HORI 2SD2578
0000A 4857024500 HEAT SINK AL EX B/K
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
R801 DDC7R0M290 POSISTOR ECPCD7R0M290
R803 RX10T339J- R CEMENT 10W 3.3 OHM J TRIPOD
SCT1 4859304130 SOCKET CRT ISHG93S
SW801 5S40101146 SW POWER PUSH SS-160-7-B
T401 50D10A2—- TRANS DRIVE TD-10A2
T402 50H0000279 FBT 1352.5094A
T801 50M4242C9- TRANS SMPS TSM-4242C9
U100 4859722630 TUNER VARACTOR TECC2949PG35W
X501 5XJ24R576G CRYSTAL QUARTZ ATS-49/U 24.576000MHZ 10PPM
LOC PART CODE PART NAME DESCRIPTION REMARK
Service part list
DDT-21H9ZTF
37
