TROUBLESHOOTING
Check Output JACK.
A. b. LINE1 E-E
YES
NO
Check IC601.
No sound in LINE1 E-E
mode.
Is 12V obtained at IC251 pin#58?
NO
Is 5V obtained at IC251 pin#40?
Check POWER circuit.
YES
NO
Are CLK and DATA obtained at IC251
pin#42,43?
Check Input LINE1 JACK
Replace IC251
YES
Is Audio signal output at IC251
pin#53, 57?
Is Audio signal at IC251 pin#9,
14?
YES
Is there MUTE(H)
at IC251 pin#36?
NO
17
19
Table of Contents
Table of Contents
2
Specifications
3
Advantages of this Product
4
Troubleshooting
6
Video Circuit
12
Waveforms
24
Voltage Charts
27
Circuit Diagram
31
Pcb Circuit Board
41
Instrument Disassembly
44
Electrical Partslist
54
