INSTRUMENT DISASSEMBL
Y
1. DECK DISASSEMBL
Y
Perform all disassembly procedures in the order presented.
When reassembling, use the reverse procedure.
Make sure that all leads/ wiring are routed correctly when reassembling.
FIG. 1
A. TOP COVER REMOV
AL
@
Remove two screws
!
Remove three screws
#
Remove two screws
43
43
45
