Daewoo DV6T834N Service Manual

26
VOLTAGE CHARTS
1. SERVO/SYSCON/TIMER MI-COM VOLTAGE CHARTS
MODE MODE MODE
PIN No.
PIN No
.
PIN No.
1 5.0 5.0 5.0 44 2.1 1.7 1.6 87 3.8 0.0 0.0
2 4.1 4.0 4.0 45 5.0 4.9 5.0 88 0.0 0.0 0.0
3 0.0 0.0 0.0 46 0.0 0.0 0.0 89 0.0 0.0 0.0
4 5.0 4.9 5.0 47 1.4 1.4 1.4 90 0.0 1.3 1.3
5 5.0 5.0 5.0 48 0.0 0.0 0.0 91 2.5 2.5 2.5
6 5.0 4.9 0.0 49 0.0 0.0 0.0 92 2.5 2.5 2.5
7 2.0 2.0 0.0 50 0.8 0.8 1.9 93 0.9 0.9 0.0
8 0.0 0.0 0.0 51 2.7 2.7 2.7 94 2.5 2.1 0.9
9 0.2 0.4 0.0 52 1.6 1.6 1.9 95 2.5 2.7 2.5
10 0.8 0.0 2.0 53 5.0 4.9 3.8 96 2.5 2.7 2.5
11 5.0 5.0 5.0 54 2.2 2.2 2.2 97 2.5 2.5 2.5
12 5.0 5.0 5.0 55 2.1 2.2 1.6 98 5.0 4.7 5.0
13 4.9 0.0 0.0 56 1.0 1.1 2.0 99 5.0 5.0 0.0
14 5.0 5.0 5.0 57 0.0 0.0 0.0 100 0.0 0.0 0.0
15 2.5 2.5 2.5 58 0.3 0.3 0.0
16 0.0 0.0 5.0 59 5.0 4.9 5.0
17 5.1 5.0 5.1 60 5.0 4.9 5.0
18 2.5 2.5 2.5 61 0.3 0.2 0.2
19 2.5 2.5 2.5 62 4.9 4.6 4.9
20 1.6 1.6 1.6 63 0.0 0.0 0.0
21 4.9 4.9 4.9 64 0.8 0.8 0.8
22 0.0 4.9 0.0 65 4.3 4.2 4.3
23 0.0 0.0 0.0 66 2.8 2.7 2.7
24 4.9 4.8 4.9 67 4.0 4.0 4.0
25 4.9 4.8 4.9 68 4.8 4.8 4.8
26 0.0 0.0 0.0 69 4.0 3.9 3.9
27 0.0 0.0 0.0 70 4.8 4.8 4.8
28 5.0 0.0 5.0 71 4.5 4.5 4.6
29 5.0 4.9 5.0 72 4.4 4.5 4.5
30 5.0 4.9 5.0 73 0.0 4.9 0.0
31 0.0 0.0 0.0 74 4.9 4.9 4.9
32 0.0 0.0 0.0 75 4.9 0.3 0.3
33 5.0 4.9 5.0 76 0.0 2.6 2.6
34 5.0 4.9 5.0 77 0.0 2.7 2.7
35 1.9 1.9 1.7 78 0.0 0.0 1.3
36 1.9 1.9 1.6 79 4.9 0.0 0.0
37 5.0 4.9 5.0 80 0.0 0.0 0.0
38 2.2 2.1 2.2 81 0.0 0.0 0.0
39 2.2 2.0 0.0 82 2.6 2.6 2.6
40 0.0 0.0 0.0 83 5.0 4.9 5.0
41 2.1 1.8 1.6 84 4.9 0.0 0.0
42 2.1 1.8 1.6 85 0.0 0.0 0.0
43 5.0 4.9 5.0 86 1.8 0.0 0.0
IC MI-COM (IC601) IC MI-COM (IC601) IC MI-COM (IC601)
STOP REC PLAYSTOP REC PLAYSTOP REC PLAY
