ELECTRICAL PARTSLIST
LOC PART CODE PART NAME PART DESCRIPTION REMARK
RJ003 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ004 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ005 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ006 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ007 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ008 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ009 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ010 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ011 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ012 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ013 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ014 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ015 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ016 HRF8000-EA R CHIP 1/8 0 OHM 3216
RJ017 HRF8000-EA R CHIP 1/8 0 OHM 3216
Z0012 PVMPJRN786 PCB MAIN RADIAL AS DW-Q73D2N-LS
C101 CEXF1A471V C ELECTRO 10V RSS 470MF (8X11.5) TP
C104 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C105 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C106 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C107 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C109 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C110 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C111 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C112 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C113 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C115 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C117 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C118 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C119 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C120 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C121 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C122 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C125 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C126 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C127 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C128 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C129 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C130 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C131 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C134 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C135 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C136 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C138 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C139 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C141 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C149 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C151 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C157 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C159 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C160 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C201 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C204 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C205 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C208 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
LOC PART CODE PART NAME PART DESCRIPTION REMARK
C209 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C210 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C211 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C212 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C221 CEXF1A471V C ELECTRO 10V RSS 470MF (8X11.5) TP
C222 CEXF1A471V C ELECTRO 10V RSS 470MF (8X11.5) TP
C223 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C224 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
C228 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C601 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C608 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C613 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C616 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C618 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C624 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
L104 5CPX688K2T COIL PEAKING 0.68UH(BLU-SILV)
Q101 TZTC2003Y- TRANSISTOR KTC2003Y-(1815Y) (AUTO)
Q201 TZTC3198Y- TRANSISTOR KTC3198Y-(1815Y) (AUTO)
Q202 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q203 TZTC3198Y- TRANSISTOR KTC3198Y-(1815Y) (AUTO)
Q204 TZTC3198Y- TRANSISTOR KTC3198Y-(1815Y) (AUTO)
Q205 TZTC3198Y- TRANSISTOR KTC3198Y-(1815Y) (AUTO)
Q206 TZTC3198Y- TRANSISTOR KTC3198Y-(1815Y) (AUTO)
Q207 TZTC3198Y- TRANSISTOR KTC3198Y-(1815Y) (AUTO)
Q208 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q209 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q210 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q211 TZTC3198Y- TRANSISTOR KTC3198Y-(1815Y) (AUTO)
Q212 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q213 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q601 TZTC3205Y- TR KTC3205Y (2236Y)
Z0013 PVMPJAN786 PCB MAIN AXIAL AS DW-Q73D2N-LS
D101 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D102 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D103 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D104 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D105 DZN4148 - DIODE 1N4148 AUTO 52MM
D106 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D107 DZN4148 - DIODE 1N4148 AUTO 52MM
D108 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D109 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D201 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D202 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
D203 DZN4148 - DIODE 1N4148 AUTO 52MM
D601 DZN4005S DIODE IN4005S 1A 600V
D602 DZN4148 - DIODE 1N4148 AUTO 52MM
D603 DZUZ5R6BSC DIODE ZENER UZ-5.6BSC
D604 DZN4148 - DIODE 1N4148 AUTO 52MM
D605 DZN4148 - DIODE 1N4148 AUTO 52MM
D606 DZN4148 - DIODE 1N4148 AUTO 52MM
D612 DZUZ7R5BSC DIODE ZENER UZ-7.5BSC(7.33-7.64)
R102 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R113 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R114 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R215 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
