34
WAVEFORMS
!
!
(P201- ) 2.0Vp-p
500mV/10usec/cm
REC(S-Y)
@
(P201-%) 2.0Vp-p
500mV/10usec
REC(V-OUT)
#
(P201-&) 2.0Vp-p
500mV/10usec
REC(Y(G))
$
(IC601-g) 4.8Vp-p
1V/20usec
C-SYNC
!
(P201-35) 500Vp-p
200mV/0.5msec
REC(A-OUT L/R)
%
(RF101-3) 400Vp-p
200mV/20usec
REC(SIF OUT)
@
(P201-79) 1Vp-p
200mV/0.2msec
REC(A-IN L/R)
#
(IC103-7) 1Vp-p
200mV/0.2msec
REC
$
(IC103-8) 1Vp-p
200mV/0.2msec
REC
1. VIDEO
2. AUDIO
