VOLTAGE CHARTS
1. SW & MTS IC VOLTAGE CHART
MODE V-SW(IC102)
PIN No. STOP REC PLAY
1 0.0 0.0 0.0
2 0.0 0.0 0.0
3 2.4 2.3 2.3
4 0.0 0.0 0.0
5 0.0 0.0 0.0
6 0.0 0.0 0.0
7 0.0 0.0 0.0
8 0.0 0.0 2.0
9 0.0 0.0 0.0
10 4.2 4.2 4.2
11 7.6 7.6 7.6
12 2.5 2.5 2.5
13 0.0 0.0 0.0
14 2.5 2.5 2.5
15 2.5 2.5 2.5
16 12.3 12.3 12.3
MODE MTS(IC103)
PIN No. STOP REC PLAY
1 2.4 2.4 2.4
2 2.4 2.4 2.4
3 2.5 2.5 2.5
4 3.0 3.0 3.0
5 2.4 2.4 2.4
6 0.0 0.0 0.0
7 1.1 1.1 1.1
8 0.0 0.0 0.0
9 4.0 4.0 4.0
10 4.4 4.4 4.4
11 1.5 1.5 1.5
12 0.2 0.2 0.2
13 2.4 2.4 2.4
14 2.3 2.3 2.3
15 2.5 2.5 2.5
16 2.4 2.4 2.4
17 2.4 2.4 2.4
18 2.4 2.4 2.4
19 4.9 4.9 4.9
20 1.0 1.0 1.0
21 2.4 2.4 2.4
22 1.4 1.4 1.4
23 2.4 2.4 2.4
24 2.4 2.4 2.4
MODE A-SW(IC101)
PIN No. STOP REC PLAY
1 5.8 5.7 5.7
2 6.0 5.9 5.9
3 6.0 5.9 5.9
4 0.0 0.0 0.0
5 5.9 5.8 5.8
6 0.0 0.0 0.0
7 0.0 0.0 0.0
8 0.0 0.0 2.0
9 7.5 7.5 7.5
10 4.2 4.2 4.2
11 0.0 0.0 0.0
12 5.8 5.7 5.7
13 5.8 5.8 5.8
14 5.9 5.8 5.8
15 6.0 5.9 5.9
16 12.3 12.2 12.2
MODE IC OP AMP(IC201)
PIN No. STOP REC PLAY
1 4.9 4.9 4.9
2 3.2 3.2 3.1
3 3.2 3.2 3.1
4 0.0 0.0 0.0
5 3.2 3.2 3.1
6 3.2 3.2 3.1
7 6.4 6.3 6.2
8 12.3 12.3 12.3
OP AMP & SYNC SEP VOLTAGE CHART
MODE IC SYNC SEP(IC104)
PIN No. STOP REC PLAY
1 2.8 2.8 2.8
2 2.0 2.0 2.0
3 0.0 0.0 0.0
4 4.9 4.9 4.9
5 4.9 4.9 4.9
