66
ELECTRICAL PARTSLIST
LOC PART CODE PART NAME PART DESCRIPTION REMARK
JP102 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP103 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP104 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP105 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP106 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP107 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP108 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP109 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP110 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP111 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
Z003 PVLAMSN786 PCB LOGIC MANUAL AS DW-Q73D2N-LS
AL01 2193100801 SOLDER WIRE SN:PB=63:37 3PI(NO FLUX)
AL02 2193011100 SOLDER WIRE 60 SNA 1.2D
AL03 2291050305 FLUX LIQUID RF-800KN
AL04 2291050306 FLUX THINNER RF-800ADD
AL05 2291140501 WAX COVER
CU101 97P4220000 CUSHION LEG EVA T=2.0
G701 DEB83D1N LED DISPLAY EB83D1N-F425-2SRVYWB
H701 10RC356VF4 IC UNIT R/RECE1VER ORC-356VF4(38KHZ)
IC701 1PT6961 - IC DRIVER P76961 32P.M SOP
JK701 97P6316800 JACK PIN DPSE-9966
JK702 97P62S09F4 CONN WAFER RV-ST4D-F16N-D16 4P(1394 ST-DIP)
P702 97P62G08E5 CONN FFC GF102-05S-TS 05P ST
PJ701 97P885X253 CONN AS 6H-6S 230MM
PJ703 97P885X255 CONN AS 6H-6S 180MM
PJ704 97P885X256 CONN AS 2S-2S 190MM
Z0032 PVLAJRN786 PCB LOGIC RADIAL AS DW-Q73D2N-LS
C701 CEXF1A471V C ELECTRO 10V RSS 470MF (8X11.5) TP
C702 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C703 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C704 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C705 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C706 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
L701 5CPX229J2T COIL PEAKING 2.2UH(RED -)
L702 5CPX229J2T COIL PEAKING 2.2UH(RED -)
L703 5CPX100J2T COIL PEAKING 10UH(BRN-BLK)
SW701 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
SW702 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
SW703 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
SW704 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
SW705 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
SW706 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
SW707 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
SW708 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
SW709 5S50101Z97 SW TACT THVV952GBA 9.5M AUTO
Z0033 PVLAJAN786 PCB LOGIC AXIAL AS DW-Q73D2N-LS(479FA)
D701 DZN4148 - DIODE 1N4148 AUTO 52MM
D702 DZN4148 - DIODE 1N4148 AUTO 52MM
D703 DZN4148 - DIODE 1N4148 AUTO 52MM
D704 DZN4148 - DIODE 1N4148 AUTO 52MM
D705 DZN4148 - DIODE 1N4148 AUTO 52MM
D706 DZUZ5R1BSB DIODE ZENER UZ-5.1BSB(4.97-5.18V)
D707 DZN4148 - DIODE 1N4148 AUTO 52MM
D708 DZUZ5R1BSB DIODE ZENER UZ-5.1BSB(4.97-5.18V)
D709 DZN4148 - DIODE 1N4148 AUTO 52MM
LOC PART CODE PART NAME PART DESCRIPTION REMARK
D710 DZUZ5R1BSB DIODE ZENER UZ-5.1BSB(4.97-5.18V)
D712 DZN4148 - DIODE 1N4148 AUTO 52MM
D713 DZN4148 - DIODE 1N4148 AUTO 52MM
JP701 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP702 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP703 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP704 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP705 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP706 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP707 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP708 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP709 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP710 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP711 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP712 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP713 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP714 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP715 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP716 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP717 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JP718 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R701 RD-AZ513J- R CARBON FILM 1/6 51K OHM J
R702 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R703 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R704 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R705 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R707 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R711 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R712 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R713 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
U001 97P65479LA PCB LOGIC 199X247/5 D1B
Z004 PVMGMSVT02 PCB MPEG MANUAL AS DW-Q73D2N-LS
AG02 2193011100 SOLDER WIRE 60 SNA 1.2D
PC01 97P62A09A8 CONN WAFER 440052-8 PLUG 8P 2.5
PC02 97P62G08ER CONN FFC GF102-25S-TS 25P ST
PC03 97P62G08E5 CONN FFC GF102-05S-TS 05P ST
PC03A 97P62G08E5 CONN FFC GF102-05S-TS 05P ST
PD01 97P62A23B6 CONN WAFER 440054-6 ST PLUG 6P
PF01 97P62A23B4 CONN WAFER 440054-4 ST PLUG 4P
PF02 97P62G08E5 CONN FFC GF102-05S-TS 05P ST
PF05 97P62G08EH CONN FFC GF102-17S-TS 17P ST
PN01 97P62A23B4 CONN WAFER 440054-4 ST PLUG 4P
XD01 5XJ24R57AE CRYSTAL QUARTZ HC-49/S 24.576000MHZ 30PP
XN01 5XJ27R00AC CRYSTAL QUARTZ HC-49/S 27.000MHZ 15PF 20PPM
XN02 5XZR03276G CRYSTAL QUARTZ SO-26 32.768000KHZ 10PPM
Z0041 PVMGJ2VT02 PCB MPEG CHIP TOP AS DW-Q73D2N-LS
AMA1 2193220007 SOLDER CLEAM RMA9154 63SN/37PB,#325
CA02 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CA03 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CA04 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CA07 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CA09 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CA10 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CA12 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CA21 HCBK182KBA C CHIP CERA X7R 50V 1800PF K 1608
