Daewoo DW-Q73D2N-LS - Page 70

69
ELECTRICAL PARTSLIST
LOC PART CODE PART NAME PART DESCRIPTION REMARK
CS37 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS38 HCFF105ZBA C CHIP CERA 16V Y5V 1MF Z 1608
CS39 HCFF105ZBA C CHIP CERA 16V Y5V 1MF Z 1608
CS40 HCFF105ZBA C CHIP CERA 16V Y5V 1MF Z 1608
CS41 HCFF105ZBA C CHIP CERA 16V Y5V 1MF Z 1608
CS42 HCFF105ZBA C CHIP CERA 16V Y5V 1MF Z 1608
CS43 HCQK471JBA C CHIP CERA 50V CH 470PF J 1608
CS44 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS46 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS47 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS48 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CS49 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS50 HCBK682KBA C CHIP CERA 50V X7R 6800PF K 1608
CS51 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CS52 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CS53 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
CS54 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS55 HCBK153KBA C CHIP CERA 50V X7R 0.015MF K 1608
CS56 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS57 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS58 HCBF225KCA C CHIP CERA 16V X7R 2.2MF K 2012
CS59 HCBF225KCA C CHIP CERA 16V X7R 2.2MF K 2012
CS60 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS61 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS62 HCBF225KCA C CHIP CERA 16V X7R 2.2MF K 2012
CS63 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS71 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CS72 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CS73 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CS74 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS75 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS77 HCBF225KCA C CHIP CERA 16V X7R 2.2MF K 2012
CS78 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS79 HRFS000-BA R CHIP 1/16 0 OHM 1608
CS80 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS81 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS82 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS83 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS85 HCBF224KBA C CHIP CERA 16V X7R 0.22MF K 1608
CS86 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS90 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS91 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS92 HCFF105ZBA C CHIP CERA 16V Y5V 1MF Z 1608
CS93 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS94 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS95 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS96 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS97 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
CS98 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
DN01 DRLS4148-B DIODE CHIP RLS4148TE-11 3415
ICA01 1CS5340CZD IC CHIP AUDIO ADC CS5340-CZZR LEAD FREE 16PIN TSSOP
ICA02 1CS4344CZD IC CHIP AUDIO ADC CS4344-CZZR LEAD FREE 10PIN TSSOP
ICC02 1AP1117E25 IC CHIP REGULATOR AP1117E25A 2.5V 2% SOT-223
ICC03 1AP1117D18 IC CHIP REGULATOR AP1117D18A 1.8V 2% TO-252
ICD01 1TSB41AB1E IC CHIP 1EEE1394 TSB41AB1PHPR 48PIN PQFP TYPE REEL
LOC PART CODE PART NAME PART DESCRIPTION REMARK
ICF01 11818E -Q IC CHIP DUAL OPTICAL CONTROL MT1818E LQFP 216 PIN TRAY
ICF02 1ADS4616AQ 16M(1X16) SDRAM ADS4616A4A-6 16M 166MHZ 50PIN TSOP TRAY
ICF04 1MX26LV80Q IC CHIP FLASH ROM MX26LV800TTC-55 48PIN TSOP TRAY
ICF06 11816E -Q IC CHIP DVD DUAL REC RF MT1816E LQFP 128PIN TRAY
ICF07 1AT93C66AD IC CHIP EEPROM AT93C66A-10SI-2.7 8SI 8PIN SOIC REEL
ICF08 1BD7902CFG IC CHIP 6CHANNEL DRIVER BD7902CFS 54PIN HSSOP-A54
ICF09 1BA5962FVC IC POWER CHIP DRIVER(FOR CD) BA5962FVM 8PIN MSOP
ICF10 1AP1117E25 IC CHIP REGULATOR AP1117E25A 2.5V 2% SOT-223
ICM01 1AD86165CQ IC CHIP DDR SDRAM ADD8616A8A-5C 256MB(4MX16X4B) 200MHZ 66PIN TSOP-2
ICM02 1G2995F1UC IC CHIP DDR REGUATOR G2995F1U AV1N=PV1N=2.5V SOP-8L
ICM03 1160ATTC7Q IC CHIP FLASH ROM MX29LV160ATTC-70 48PIN TSOP
ICM04 124LC16BTC IC CHIP EEPROM 24LC16BT-I/SN 16K 8 PIN SOIC REEL
ICN01 1MT8105GEQ IC CHIP MPEG CODEC MT8105GE LQFP 256PIN TRAY
LA01 HRFT000-CA R CHIP 1/10 0 OHM 2012
LA02 HRFT000-CA R CHIP 1/10 0 OHM 2012
LA05 HRFT000-CA R CHIP 1/10 0 OHM 2012
LC01 HRFT000-CA R CHIP 1/10 0 OHM 2012
LC02 HRFT000-CA R CHIP 1/10 0 OHM 2012
LC03 HRFT000-CA R CHIP 1/10 0 OHM 2012
LC04 HRFT000-CA R CHIP 1/10 0 OHM 2012
LC05 HRFT000-CA R CHIP 1/10 0 OHM 2012
LC06 HRFT000-CA R CHIP 1/10 0 OHM 2012
LC07 HRFT000-CA R CHIP 1/10 0 OHM 2012
LD01 HRFT000-CA R CHIP 1/10 0 OHM 2012
LD02 HRFT000-CA R CHIP 1/10 0 OHM 2012
LF01 HRFT000-CA R CHIP 1/10 0 OHM 2012
LF02 HRFT000-CA R CHIP 1/10 0 OHM 2012
LF03 HRFT000-CA R CHIP 1/10 0 OHM 2012
LF04 HRFT000-CA R CHIP 1/10 0 OHM 2012
LF05 HRFT000-CA R CHIP 1/10 0 OHM 2012
LM01 HRFT000-CA R CHIP 1/10 0 OHM 2012
LN01 HRFT000-CA R CHIP 1/10 0 OHM 2012
LN02 HRFT000-CA R CHIP 1/10 0 OHM 2012
LN03 HRFT000-CA R CHIP 1/10 0 OHM 2012
LN04 HRFT000-CA R CHIP 1/10 0 OHM 2012
LN05 HRFT000-CA R CHIP 1/10 0 OHM 2012
LN06 HRFT000-CA R CHIP 1/10 0 OHM 2012
LN07 HRFT000-CA R CHIP 1/10 0 OHM 2012
PF04 97P62Y3650 CONN FFC SMD 05003HR-50A01 RA 0.5 SMD
RA01 HRFT519JCA R CHIP 1/10 5.1 OHM J 2012
RA02 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RA06 HRFS220JBA R CHIP 1/16W 22 OHM J 1608
RA07 HRFS220JBA R CHIP 1/16W 22 OHM J 1608
RA08 HRFS220JBA R CHIP 1/16W 22 OHM J 1608
RA09 HRFS220JBA R CHIP 1/16W 22 OHM J 1608
RA11 HRFS122JBA R CHIP 1/16 1.2K OHM J 1608
RA12 HRFS911JBA R CHIP 1/16 910 OHM J 1608
RA13 HRFS122JBA R CHIP 1/16 1.2K OHM J 1608
RA14 HRFS911JBA R CHIP 1/16 910 OHM J 1608
RA15 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RA16 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RA17 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RA18 HRFS101JBA R CHIP 1/16 100 OHM J 1608
RA19 HRFS101JBA R CHIP 1/16 100 OHM J 1608
RA20 HRFS101JBA R CHIP 1/16 100 OHM J 1608
