11. EXPLODED DIAGRAM AND PARTS LIST.
■ DWC-052C,DWB-052C PARTS LIST
NO CODE COMPONENTS Q'TY SPECIFICATION REMARK
1 3110300100 PAN BASE 1 SGCC T1.0
2 3116000100 COMP BOLT 3 M8 DWC-052C
3116000400 COMP BOLT 3 M8 DWB-052C
3 3112500100 GUIDE WIN LOWER 1 SGCC T0.8 DWC-052C
4 3118100100 PAN DRAIN 1 EPS
5 3110000200 AS EVA 1 2R1C, 330X209X25
6 3114400300 PIPE EVA IN 1 C1220T-OL, OD7.0XT0.7
7 3110001900 AS PIPE SUCTION 1 C1220T-OL, OD7.94XT0.7 DWC-052C
3110005600 AS PIPE SUCTION 1 C1220T-OL, OD7.94XT0.7 DWB-052C
8 3117100100 AS COMPRESSER 1 RM5455GQ87 DWC-052C
3117100800 AS COMPRESSER 1 KH091VFHC DWB-052C
9 - GASKET 1
10 - TERMINAL COVER 1
11 - GASKET NUT 1
12 - NUT FLANGE 1
13 (AHT941C003) GROMMET 3 EPDM DWC-052C
3116000300 GROMMET 3 EPDM DWB-052C
14 - WASHER 3
15 - NUT 3
16 - SPRING 1
17 - OVERLOAD PROTECTOR 1
18 3112700300 HARNESS COMP 1 UL1015 3*16AWG
19 3110000300 ASSY CONDENSER 1 2R1C, 380X304X25
20 3114400100 PIPE DISCHARGE 1 C1220T-OL, OD6.35 DWC-052C
3114401600 PIPE DISCHARGE 1 C1220T-OL, OD6.35 DWB-052C
21 3110002000 AS PIPE CAPILLARY 1 ID1.0, OD3.2X1000
22 3101202800 CLIP FAN 2 SK5
23 3111800100 FAN BLOWER 1 ABS730
24 3116600100 SCROLL 1 EPS
25 3114200100 PANEL HOUSING 1 SGCC T0.8
26 7122401211 SCREW 3 T2S 4X12
27 3118000100 MOTOR FAN 1 A9520KC030(DMI) DWC-052C
3118000400 MOTOR FAN 1 (S.W) DWC-052C
3118000500 MOTOR FAN 1 (O.S) DWC-052C
3118000800 MOTOR FAN 1 A9520CC020(DMI) DWB-052C
28 7S432X2081 SCREW TAPTITE 4 TT3 TRS 3X8 MFZN
29 3113800400 LOCK TWIST STANDOFF 1 DASTL-3NA
30 3110700100 BUSHING 1 DACB-012(73MM)
31 3111400100 COVER ORIFICE 1 PP(M540)
32 3111800200 FAN PROPELLER 1 ABS+GF
33 3114500300 PLATE SCROLL 1 EPS
34 3113000100 HOLDER EVA 1 SGCC T0.6
35 3110500100 BOX CONTROL 1 SGCC T0.6
36 3111300100 CORD POWER 1 125V, 13A, SJT3*16AWG DWC-052C
3111300300 CORD POWER 1 250V, 16A DWB-052C
37 3111200300 CLAMP POWER CORD 2 PP
38 3116900100 CAPACITOR 1 4/40µF 370V DWC-052C
3116900200 CAPACITOR 1 4/40µF 370V DWC-052C
3116900800 CAPACITOR 1 2/13µF 400V DWB-052C
39 3111200100 CLAMP CAPACITOR 1 SGCC T0.6 DWC-052C
3101200600 CLAMP CAPACITOR 1 SGCC T1.0 DWB-052C
40 3118500100 THERMOSTAT 1 125/250VAC,20/80A,16~31°C
3118500200 THERMOSTAT 1 125/250VAC,20/80A,16~31°C
41 3118500300 ROTARY S/W 1 SRB-315-4-10D
42 3112700200 HARNESS ROTARY 1 UL1015 16AWG 105¢™
43 3113500400 LABEL CIRCUIT 1 ART PAPER
44 3110800100 CABINET 1 SGCC T0.6
45 3112500200 GUIDE WINDOW TOP 1 SGCC T0.8 DWC-052C
46 3112400200 GRILLE FRONT 1 HIPS
47 3116500100 BLADE VERTICAL 1 PP
48 3111900200 FILTER 1 HIPS
49 3110001400 AS KNOB 2 ABS720
50 3111600100 DECO FRONT 1 PC FILM
51 3118400100 SEAL G/FRONT(1) 1 F-PE DWB-052C
52 3110012400 ASS'Y SEAL G/FRONT(2) 1 F-PE DWB-052C
53 3110012500 ASS'Y SEAL G/FRONT(3) 1 F-PE DWB-052C
54 3118400200 SEAL G/FRONT(4) 1 F-PE DWB-052C
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
