40
EXPLODE VIEW AND PARTS LIST
E01 CABINET 3610811101 SGCC(GI), 0.7TX825.7X1630.8 1 DWD-FD'S
E02 SPECIAL SCREW 3616029100 M4x12.5, MACHINE 2
E03 FRAME UPPER 3612205801 SGCC T1.0 55X580 1
E04 SCREW TAPPING 3616029950 TTS"S" HEX F/L 4X8 4
E05 FRAME TOP *L 3612205601 SGCC T1.4 52x500 1
E06 FRAME TOP *R 3612205701 SGCC T1.4 52x500 1
E07 STOPPER SPRING 3615202200 POM 2
E08 COVER *B 3611427100 PP 1
E09 SENSOR PRESSURE 3614825300 5V DRUM DL-DW11 INLET 90 1
E10 FRAME LOWER 3612205501 SGCC T1.0 160X580 1
E11 BASE U-L 3610392201 SGCC T1.4 100x500 1
E12 BASE U-R 3610392301 SGCC T1.4 100x500 1
36189L5700
40W 110-127V/60HZ B20-3 DRUM(6KG.FILTER) CU
DWD-FD'S(110-127/60)
E13 UNIT DRAIN PUMP AS 36189L5K20 AL.220-240/50 B20-6 30W 6KG 1
DWD-FD'S(220-240/50)
36189L5J20 AL.220/60 B20-5 35W 6KG
DWD-FD'S(220/60)
E14 CAP WATER REMAIN 3610916800 PP 1
E15 HOSE WATER REMAIN 3613268700 EPDM, ID8.5, L200 1
E16 LEG ADJUST AS 3617703811 FOOT + NUT 4
E17 EMI FILTER 3611909320
K25,MIN7MH,X0.47U.Y222.VAR471K.NON FUSE
1 DWD-FD'S(EU)
E18 CUFF DRAIN HOSE 3616802500 PP 1
E19 GUIDE DRAIN HOSE 3612510400 PP 1
E20 HOSE DRAIN INNER AS 3613268401 L=870(changed) 1
E21 CLAMP HOSE 3611204701 D26 1
E22 REACTOR AS 3615800100 DWD-800W RT--046B 1 OPTION
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
To Next Page
