33
PARTS LIST
NO PARTS CODE PARTS NAME DESCRIPTION Q’TY REMARK
A18 3611794500 DOOR F ABS 1
A19 3611504100 CUSHION DOOR CR 2
A20 3612604100 HANDLE DOOR PP 1
A21 3616008500 SPECIAL SCREW M5(T1)X10 1
A22 3610909700/10 CAP PLATE L/R ABS 1
A23 3611302900 POWER CORD AS 3X0.75, 300X2, L=1800 1 CP-2PIN
3611302800 A VCTFK 2X0.75 2.3M FLAT 2PIN
3611302600 H H05V/4A, FERRITE 1 ITALIAN 3PIN
3611303300 GTSA-3 3X0.75 ARGENTINE
A24 3618918400 UNIT FUSE FILTER AC 250V/4A, FERRITE 1
3618918400 AC 250V/8A, FERRITE
3618914810 AC 250V/5A, FERRITE TUV
A25 3612757600 HARNESS AS NON-PUMP 1
220~240:315mA(5F3GB3102L)
3612757610 SINGLE V/V
100~130:600mA(5FKGD6012S)
3612757620 PUMP
B01 3611201000 CLAMP HSW3, MFZN D36 1 NON-PUMP
B02 3613213500 HOSE DRAIN O AS EVA L=950MM 1 NON-PUMP
B03 3614514600 PLATE UPPER PP 1
B04 7112501411 SCREW TAPPING T1 TRS 5X14 MFZN 8
B05 3615302210 SUPPORTER TUB BL SPG 1.4T 1
B06 3615302310 SUPPORTER TUB BR SPG 1.4T 1
B07 3615302410 SUPPORTER TUB FR SPG 1.4T 1
B08 3615302510 SUPPORTER TUB FL SPG 1.4T 1
B09 3611413600 COVER BACK SPG 0.5T 1
B10 3618920000 ASSY CONDENSER 11.4µF+60µH 1 ~240V
3618919900 13.5µF+60µH 220V(1098)
3618921100 15.0µF+60µH 220V(1398)
3618920500 41.6µF+60µH 127V
3618920400 54.0µF+60µH 110V
B11 3612603300 HANDLE CABINET PP 1
B12 3610068700 HARNESS OUTER 50/0.18 GN ST710489-2 1
B13 4509D10020 FOOT BUTYL RUBBER 2
B14 3610310200 BASE U PP 1
3610310210 PP, PUMP
3610312200 PP(1398) DWF-1398
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
