PARTS LIST
No. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
D01
3611417700
COVER TUB PP 1
200
3611413900 240
D02 3618807100 TUB O 1098 1
D03
3619805400
SUSPENSION AS(B)
ROD=592 SPR=102(BLACK),100C,S
2
200
3619803900 1398, BLACK, BACK DWF-301W
D04
3619805500 SUSPENSION AS(A) ROD=592 SPR=112(YELLOW),100C,S
2
200
3619803800 SUSPENSION AS(F) 1398, YELLOW, FRONT DWF-301W
D05 3613208901 HOSE OVERFLOW PELD, L=280MM 1
D06 3615408400 VALVE DRAIN AS VE TYPE 1
D07 3613218500 HOSE DRAIN I AS LDPE+EVA, L=219.5 1
D08 3610387400 BASE SECEN 2.0T 1
D09 3616007000 SPECIAL SCREW SCM24H, 6.5x24 14
D10
36196TAN30
DRAIN MOTOR
SV-HJ7T22D, 100-110V, 50/60HZ 1
36196TAN20 SV-KL6T22D 120-127 60HZ 1 MEX
D11
3617310300
GEAR MECHANISM
GM-1300-YS6P0
1
200
3617310200 GM-1300-KS6P2(SPUR) DWF-301W
D12 7341801511 BOLT HEX 6B-1 8x15 MFZN 4
D13 3618301300 PROTECTOR GEAR SBHG 1.6T 1
D14 3616590220 BELT V M20.5, AGING 1
3964221290 W1D50CA015, 110-127V/60Hz, 1490 KET 3P 1 200, 240
D15 3964321280 MOTOR CONDENSER W1S50UA019, 220V/60HZ 1
3964221030 WM244EA012, 110-127V/60Hz 1 260P
D16 3611502700 CUSHION DOWN POM(8MM) 2
D17 3612757030 HARNESS EARTH INNER L ID=4.3, R ID=8.3, L=810 1
D18 7650802528 BOLT HEX 6B-1 8x25 PW(3x28) MFZN 2
D19 3610402931 BODY BUBBLE AS 104KR, 2700MM 1
D20
3618432000
PULLEY MOTOR AS
M-TYPE, DS=10, DP=48.5, 60HZ 1
3618403610 M-TYPE, DS=12, DP=48.5, 60HZ 1 260P
