PARTS DIAGRAM
A01 36142T3400 PANEL *B ABS, DWF-260AX 1 A5, A9, M9
36142T3410 DWF-260AX SPRAY M6, M7
A02 PRPSSW4N90 PCB AS
DWF-204AY, NORMAL PUL, S, HOT, PP, NON-BB
1
A03 3613068200 HOLDER FUNCTION HIPS, DWF-204AY 1
A04 36116DAY00 DECORATOR FILM PC FILM, DWF-204AY 1
A05 3615516200 WINDOW DISPLAY TR-ABS, DWF-204AY 1
A06 3616646680 BUTTON PW/ST ABS, DWF-204AY 1 A5, A9, M9
3616646750 DWF-204AY SPRAY M6, M7
A07 3615516600 DECO WINDOW AS DWF-204AY, SPRAY 1 A5
3615516500 DWF-204AY, COATING A9, M6, M7, M9
A08 36142T3560 PANEL *F ABS, DWF-204AY 1 A5, A9, M9
36142T3570 UV_BASE, DWF-204AY SPRAY M6, M7
A09 3615516000 WINDOW COURSE TR-ABS, DWF-204AY 1
A10 3613408700 KNOB COURSE AS DWF-260AX, KNOB COURSE AS 1 A5, A9, M9
3613408720 DWF-151AX M6, M7
A11 3613068100 HOLDER COURSE HIPS, DWF-204AY 1
A12 3616646670 BUTTON FUNCTION ABS, DWF-204AY 1 A5, A9, M9
3616646720 DWF-204AY SPRAY M6, M7
A13 36190470B0 SWITCH SAFETY SF-030A31, 1
A14 3619045400 SWITCH COVER GSM-V16183A4 250V 16A 1
A15 3614801650 SENSOR PRESSURE CDL-D17N,3PIN,L=620,15DO 1
A16 3618912200 UNIT CAPACITOR AS 45.6UF 200VAC, CAN TYPE 1
A17 3611338300 CORD POWER AS 750M,201AS,EP3PIN 1
A18 3615416311 VALVE INLET
DR-12AS:C-R-H.110-130V50/60HZ NON-O.P RUBBER
1
A19 3610394400 BODY DETERGENT ABS. DWF-260AX 1
A20 3618111900 NOZZLE DETERGENT PP. DWF-260AX 1
A21 3612905300 HINGE BOSS *L ABS, DWF-26'S(HINGE DOOR) 1
A22 3612905400 HINGE BOSS *R ABS, DWF-26'S(HINGE DOOR) 1
A23 3614542400 PLATE *T ABS,DWF-260AX 1
3614542410 ABS, UV_BASE, 260A 1
A24 3612902400 HINGE DOOR POLYACETAL 2
A25 36111T2L00 CASE DETERGENT ABS, DWF-260AX 1 A5, A9, M9
36111T2L10 CASE DETERGENT ABS, UV_BASE DWF-260AX 1 M6, M7
A26 3610907800 CAP SOFTENER PP 1
A27 7112503011 SCREW TAPPING T1S,TRS,5*30 MFZN 2
A28 3611561400 CUSHION DOOR NBR, DWF-200A 2
A29 36117ADE50 DOOR *O ABS, DWF-204AY 1 A5, A9, M9
36117ADE70 UV_BASE,DWF-204AY SPRAY M6, M7
A30 361A114400 DOOR GLASS DWF-150AX 4T*479*323 1
A31 36117ADE60 DOOR *I HIPS, DWF-204AY 1
A32 7115401630 SCREW TAPPING T1 FLT 4X16 SUS WHITE PAINTING 12
A33 3611559900 CUSHION DOOR NR 2
A34 3615118300 SPRING DOOR *L DWF-260AX 1
A35 3615118400 SPRING DOOR *R DWF-260AX 1
A36 361279D430 HARNESS AS DWF-204AY LOW PUMP C-H-R,NB 1
⏿
Parts List
No. Item Code Item Materials and Sizes Q'TY Remarks
To Next Page
