PARTS DIAGRAM
A01 3611432400 COVER PANEL B ABS 202AX 1
A02 3615510900 WINDOW SELECTION TR-ABS 202AX 3
A03 3613408300 KNOB SELECTION ABS 202AX 3
A04 3610919800 CAP SELECTION ABS 202AX 3
A05 3615510700 WINDOW DISPLAY TR-ABS 202AX 1
A06 3616646200 BUTTON FUNCTION ABS 202AX 1
A07 3610919900 CAP COURSE ABS 202AX 1
A08 36116DG800 DECO KNOB CPURSE ABS 202AX 1 Cr Plating
A09 3613408400 KNOB COURSE ABS 202AX 1
A10 3616646300 BUTTON FUNCTION DWF-202AX 1
A11 3615510800 WINDOW COURSE TR-ABS 202AX 1
A12 36142T3200 PANEL B ABS 202AX 1
A13 361A101700 DOOR O SECC 1T 1 WHITE SPRAY
A14 3613702600 LEVER SAFETY SW ABS DWF-200A 1
A15 7125401408 SCREW TAPPING T2S FLT 4X14 SUS430 5
A16 361A101900 DOOR HINGE L SUS;D=6,DWF-200A 1
A17 361A101800 DOOR HINGE R SUS;D=6,DWF-200A 1
A18 361072200 BUSHING HINGE POM, DWF-200A 4
A19 3616009900 SPECIAL SCREW T2S FLT 3.5X7 SUS430 4
A20 36122UDJ00 FRAME GLASS L ABS 202AX 1
A21 36122UDK00 FRAME GLASS R ABS 202AX 1
A22 36117ADB00 DOOR GLASS GLASS 1
A23 36117ADC00 DOOR I ABS 202AX 1
A24 3611432500 COVER SCREW PC 0.3T 202AX 14
A25 3614801650 SENSOR PRESSURE C0I-D17N, 3PIN, L=620,15D 1
A26 3619044180 SAFETY SWITCH AS
SF-03013, F187, CU/T=9, CU/L=110, L=174
1
A27 3618965010 UNIT CAPACITOR AS 58UF 230VAC 60UH CAN 1
A28 3618946412 UNIT BUBBLE PUMP AS C DK-115K1, H:350MM 1
A29 3618304100 PROTECTOR PLATE SECC DWF-200A 2
A30 7122401411 SCREW TAPPING T2S TRS 4X14 MFZN 2
A31 3614529800 PLATE T ABS, DWF-200A 1
A32 3611561400 CUSHION DOOR NBR, DWF-200A 2
A33 7122401411 SCREW TAPPING T2S TRS 4X14 MFZN 2
A34 3610907800 CAP SOFTENER PP 1
A35 3611138100 CASE DETERGENT ABS 1
A36 3618102900 NOZZLE DETERGENT PP 1
A37 3610430100 BODY DETERGENT ABS 1
A38 3615407930 VALVE INLET 110-130V 50/60Hz DR-98M-2 1
A39 3611338300 CORD POWER AS 750M ,201AS,EP3PIN 1
A40 3614801650 HARNESS AS DWF-202AX BUBBLE,127V/60Hz 1
■
Parts List
No. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
To Next Page
