34
PARTS DIAGRAM
Parts List
NO.
PARTS CODE
PARTS NAME DESCRIPTION Q'TY REMARK
NORMAL UV SPRAY
A01 3614530200 3614530201 PLATE T ABS 1
A02 3618102500 - NOZZLE DETERGENT PP, 200C 1
A03 3611131700 3611132720 CASE DETERGENT ABS, RINSE 1
A04 3610907800 - CAP SOFTNER PP 1
A05 3614280100 3614280101 PANEL B ABS 1
A06 36117AAK00 36117AAK01 DOOR B ABS 1
A07 3615110110 - SPRING DOOR DWF-100M 1
A08 3611559900 - CUSHION DOOR NR 2
A09 3612902400 - HINGE DOOR POLYACETAL 1
A10 36117AAJ01 36117AAJ00 DOOR F ABS 1 KW
A11 3612607700 - HANDLE DOOR ABS 1 UV SPRAY
A12 3612607801 3612607800 HANDLE CAP ABS 1
A13 36117AAG00 36117AAG01 DOOR F ABS 1 KA, KR, KC
A14 3612607400 3612607401 HANDLE DOOR ABS 1
A15 3612607500 3612607501 HANDLE CAP ABS 1
A16 3614280301 3614280300 PANEL F ABS 1 KW
A17 3611629700 - DECORATOR PANEL F ABS, INMOLD 1 IN-MOLD
A18 3611630000 - DECORATOR BAR ABS 1 UV SPRAY
A19 3618971100 - UNIT LEVELER LEVELER 1
A20 3614280400 3614280201 PANEL F ABS 1 KA
A21 3611629900 - DECORATOR PANEL F PC FILM 1
A22 3614280200 3614280201 PANEL F ABS 1 KR, KC
A23 3611629600 - DECORATOR PANEL F PC FILM 1
A24 7112503011 - SCREW TAPPING T1 TRS 5X30 MFZN 2
A25 3610902600 - CAP REAR CR 2
A26 3618956720 - UNIT FILTER 7A, 12MH(K8-2) 1 KW, KA
3612792920 - 220-240V C/H NON-PUMP N/RADICAL
3612792910 - 220-240V C/H NON-PUMP RADICAL
3612792940 - 220-240V C ONLY NON-PUMP N/RADICAL
3612792930 - 220-240V C ONLY NON PUMP RADICAL
3612792990 - 220-240V C/H PUMP N/RADICAL
A27
3612792985 -
HARNESS AS(200'S)
220-240V C/H PUMP
1
RADICAL
3612792960 - 100-127V C ONLY NON-PUMP N/RADICAL
3612792950 - 100-127V C ONLY NON-PUMP RADICAL
3612792970 - 100-127V C/H PUMP N/RADICAL
3612792980 - 100-127V C/H PUMP RADICAL
A28 3619006310 - SWITCH SAFETY AS SF-030A13 CUSHION T=9MM 1
A29 3614802312 - SENSOR PRESSURE 15µµ 2-PIN CDN2-D01N-1 1
A30 4507D08150 - CLAMP MFZN HOSE ID=7PIE 1
A31 3618919950 - UNIT BUBBLE AS CDK-115B L=650, 110/60 1 260'S
To Next Page
