Daewoo DWF-270TAP - Page 36

35
PARTS DIAGRAM
NO.
PARTS CODE
PARTS NAME DESCRIPTION Q'TY REMARK
NORMAL UV SPRAY
A32 3606007400 - SPECIAL SCREW T2S TRS 4X10+24 2 260'S
3615407100 - 220V/60HZ, C&H&R 1
3615407110 - 110V/50.60HZ,C&H&R 1
3615407120 - 110-130V/60HZ, C&H&R 1
3615407130 - 220-240V/50HZ, C&H&R 1
A33
3615407140 -
VALVE INLET AS
100V/50,60HZ, C&R 1
3615407150 - 100-130V/60HZ, C&R 1
3615407160 - 220V/60HZ, C&R 1
3615407170 - 220-240V/50HZ, C&R 1
3615407171 - 220-240V/50HZ. ANG-180 1
3615408300 - AC220-240V/50HZ. COLD ONLY 1
3618911300 - 12.5µfi 400VAC CAN TYPE 1 220-240V
3618911400 - 13.5µfi 400VAC CAN TYPE 1 220V
A34 3618911800 - UNIT CAPACITOR 41.6µfi 400VAC CAN TYPE 1 127V MEX
3618912400 - 54µfi 200VAC CAN TYPE 1 110V
3618955300 - 16.5µfi 200VAC CAN TYPE 1 110V, 260'S
3611305100 - 3*0.75 2.3M 1 KOREA
3611305110 - U VCTF 3*0.75 2.3M 1 PERU
3611305500 - A-VCTFK 2*0.75 2.3M GY 1 MEXICO
3611304610 - N LFC-2R 3*0.75 2.3M GY 1 AUSTRALIA
3611336650 - F H05W 3*0.75 2.3M WH 1 CHILE
3611304810 - RW-300/500 3*0.75 2.3M 1 CHINE
A35
3611304910 -
POWER CORD AS
VCTF 3*0.75 2.3M 1 INDIA
3611305310 - H05W-F 3*0.75 2.3M WH 1 MALAYSIA
3611305410 - H05W-F 3*0.75 2.3M BK 1 SINGAPORE
3611305810 - H05W-F 3*0.75 2.3M GY 1 SOUTH AFRICA
3611305610 - F H05W 3*0.75 2.3M BK 1 USSR, SPAIN
3611336030 - H05W-F 3*0.75 2.3M GY 1 ARGENTINA
3611302900 - 3*0.75 300*2 L=1800 1 KOREA
3611302820 - A-VCTFK 1.9M 1 TAIWAN
PRPSSW2Y03 - 100-127V PUMP, DUAL VALVE
PRPSSW2Y01 - 220-240V PUMP, DUAL VALVE
PRPSSW2Y04 - 100-127V PUMP, SINGLE VALVE
A37
PRPSSW2Y05 -
PCB AS
220-240V PUMP, SINGLE VALVE
1 KR
PRPSSW2Y06 -
100-127V NON-PUMP, DUAL VALVE
PRPSSW2Y00 - 220-240V NON-PUMP, DUAL VALVE
PRPSSW2Y02 - 100-127V NON-PUMP,SINGLE VALVE
PRPSSW2Y07 - 220-240V NON-PUMP,SINGLE VALVE
PRPSSW3Y50 - 100-127V PUMP, DUAL VALVE
A36
PRPSSW3Y60 -
PCB AS
220-240V PUMP, DUAL VALVE
1 KW, KA
PRPSSW3Y70 - 100-127V PUMP, SINGLE VALVE
PRPSSW3Y80 - 220-240V PUMP, SINGLE VALVE
MEXICO
