36
PARTS DIAGRAM
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
PRPSSW3Y20 100-127V NON-PUMP, DUAL VALVE
A36
PRPSSW3Y00
PCB AS
220-240V NON-PUMP, DUAL VALVE
1 KW, KA
PRPSSW3Y30
100-127V NON-PUMP,SINGLE VALVE
PRPSSW3Y40
220-240V NON-PUMP,SINGLE VALVE
A36
PRPSSW3Y90
PCB AS(260'S)
100-127V NON-PUMP,SINGLE VALVE
1
PRPSSW3YA0 100-127V PUMP, DUAL VALVE MEXICO
3612793020 220-240V C/H NON-PUMP N/RADICAL
3612793010 220-240V C/H NON-PUMP RADICAL
3612793040 220-240V C ONLY NON-PUMP N/RADICAL
3612793030 220-240V C ONLY NON PUMP RADICAL
A27
3612793090
HARNESS AS(260'S)
220-240V C/H PUMP
1
N/RADICAL
3612793085 220-240V C/H PUMP RADICAL
3612793060 100-127V C ONLY NON-PUMP N/RADICAL
3612793050 100-127V C ONLY NON-PUMP RADICAL
3612793070 100-127V C/H PUMP N/RADICAL
3612793080 100-127V C/H PUMP RADICAL
A28 3619006310 SWITCH SAFETY AS SF-030T TUBE 1
260'S
A29 3614802312 SENSOR PRESSURE 15µµ 2-PIN CDN2-D02N-1 1
B01
3613213560 HOSE DRAIN O 1089CTE 950MM
1
NON PUMP
3613226700 HOSE DRAIN O AS LD-PE/EVA L=1600 PUMP PUMP
B02 3614514600 PLATE UPPER PP 1
B03 3615302220 SUPPORT TUB BL SPG 1.6T 1
B04 3615302320 SUPPORT TUB BR SPG 1.6T 1
B05 3615302420 SUPPORT TUB FL SPG 1.6T 1
B06 3615302520 SUPPORT TUB FR SPG 1.6T 1
B07 7122501211 SCREW TAPPING T2S TRS 5X12 MFZN 8
B08 3611413600 COVER BACK SPG 0.4T 1
B09
3610808011
CABINET
PAINTING 0.6T 1 KA, KR, KC
3610808020 PCM 0.6T 1 KW
B10 3617702300 LEG FIX THERMAL PLASTIC ELASTOMER 2
B11 3610310200 BASE U PP 1 200'S
B12 3617702120 LEG ADJUST AS SCREW 4X14 2
B13 3612603300 HANDLE CABINET PP 2
B14 3610068700 HARNESS OUTER 50/0.18GREEN,ST710489-2 1
2WIRE POWER CODE
B15 3611402711 COVER UNDER PP 1 OPTION
B16 3611405320 COVER PUMP PP 1
B17 7122501411 SCREW TAPPING T2S TRS 5X14 MFZN 1
B18 3611901531 FILTER AS DWF-5590 DPNF E-TYPE 1
3618964550 220V/50HZ
B19
3618964530
UNIT DRAIN PUMP VSF L-1250 #1806 EARTH L=410 1
230-240V/50HZ
3618964560 220V/60HZ
3618957410 110-127V/60HZ
B09 3610808012 CABINET PAINTING 0.7T 1 260'S
To Next Page
