PARTS DIAGRAM
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
B11 3610312200 BASE U PP 1
C01 3616105400 BALANCER AS 100'S, HIDDEN 1 KW, KA, KC
C02 3612202900 FRAME FALL PP 1
C03 3611904700 FILTER AS 100'S LINT FILTER AS 2
C04 3618819700 TUB I SUS 0.6T, 102KA 1
C05 3612507210 GUIDE FILTER HIDDEN FILTER (SUS 0.6T) 3
C06 3616008600 SPECIAL BOLT SUS 6
C07 3616008700 SPECIAL NUT SUS 6
C08 3611906000 FILTER FRAME ABS, NAN0 FILTER 1
C09 3611905800 FILTER BODY PP 1
C10 3611905900 FILTER LINT ABS + SUS ∏¡ INSERT 1
C11 3611906100 FILTER FIX ABS 1
C12 3618815205 TUB U NANO SILVER, 1098 1
C01 3616104000 BALANCER AS DWF-1094 1 KR
C03 3611903100 FILTER AS DWF-1094, PP 2
C04 3618806900 TUB I SUS430D 1
C05 3612504100 GUIDE FILTER DWF-1094 2
C12 3618807002 TUB U 94'S +M/B +RIB 1
C13 3616003700 SPECIAL SCREW SUS 5.5X16 12
C14 3616003700 SPECIAL SCREW SUS 5.5X16 12
C15 3617201200 FLANGE TUB 10KG 3-FOOT 1 200'S
C12 3618815504 TUB U NANO SILVER 1 260'S
C15 3617200200 FLANGE TUB ADC 12 1 NANO SILVER
C16 3616007000 SPECIAL SCREW SCM24H 6.5X24 6 260'S : 12EA
C17 4507D83080 SPECIAL NUT SUS 304 1
C18 3616003720 SPECIAL SCREW SUS 6X26.5 1
C19
3619707701
PULSATOR
NANO SILVER, 102KA 1
NANO SILVER: KW,KA,KC
3619707700 DWF-100K, PP, IMPELLER 1 KR
C20 3610915800 CAP PULSATOR ABS, 104KR 1 IMPELLER
C21 3619707702 PULSATOR 105KWD, SUS 1 KWD
C22 3610916000 CAP PULSATOR 102KWD, ABS 1 STAINLESS
D01 3611417700 COVER TUB PP 100M 1 200'S
D02 3618807100 TUB O PP 1098 1
D04 3619805400 SUSPENSION AS(A) 100C'S ROD=592 SPR=102 2
200'S
D05 3619805500 SUSPENSION AS(B) 100C'S ROD=592 SPR=112 2
D06 3613208901 HOSE OVERFLOW PELD, L=280MM 1
D07 3615408400 VALVE DRAIN AS 1098'S, VE TYPE 1
D08 3613218500 HOSE DRAIN I AS LDPE+EVA L=219.5 1
D09 3610387400 BASE SECEN 2.0T 1
D10 3616007000 SPECIAL SCREW SCM24H,6.5X24 14
D11 36189H1R50 MOTOR SYNCHRONOUS 220-240V/5,60HZ KD-KW22 1
36196L1R50 220/50-60 SV-MX7T06D 1
36189L1R50 100-130V, KD-KW11LD 1 MEXICO
