38
PARTS DIAGRAM
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
D11 36196T1R50 MOTOR SYNCHRONOUS 100-110/50,60 SY-HJ7106D 1
D12 3617309640 GEAR MECHANISM GM-1300-KS6P0 1 200'S
D13 7341801511 BOLT HEX 6B-1 8X15 MFZN 4
D14 3618301300 PROTECTOR GEAR SBHG 1.6T 1
D15
3616590220
BELT V
M20.5, AGING
1
3616590230 M21, AGING
3964321264 W1S50UA018 220V/60HZ
3964821120 W1S50CA011 110-127V/60HZ
D16 3964221250 MOTOR CONDENSER W1D50CA013 110-127V/60HZ 1 200'S
3964821330 W1D50JA011 120-127V/60HZ
3964510431 W1S50VA011 220-240V/50HZ
D17 3611502700 CUSHION DOWN POM(8MM) 2
D18 3612757020 EARTH INNER L ID=4.3, R ID=8.4 L=560 1
D19 7650802528 BOLT HEX 6B-1 8X25 PW(3X28) MFZN 2 260'S : 4EA
D20 3610402931 BODY BUBBLE AS 104KR, 2700MM 1 200'S
D22
3618432000 M-TYPE DS=10 DP=48.5 60HZ 1
3618431900
PULLEY MOTOR AS
M-TYPE DS=10 DP=53 50HZ 1
200'S
D21
3618401400 ADC-12 DS=12 DP=48.5 60HZ 1
3618401420 ADC-12 DS=12 DP=53 50HZ 1
D01 3611413900 COVER TUB PP 1 260'S
D03 3613265900 HOSE BUBBLE ID=4.0, L=1150MM 1
D05 3619803800 SUSPENSION AS(F) DWF-1398 YELLOW FRONT 2
D04 3619803900 SUSPENSION AS(B) DWF-1398 BLACK BACK 2
D12 3617309640 GEAR MECHANISM GM-1300-KS6P2 1
D16 3618961300 UNIT MOTOR AS W1N44EB020 110V/60HZ 1
D22 3618403510 PULLEY MOTOR AS ADC-12 M-TYPE DS12 DP52.5 1
