PARTS DIAGRAM
§§ è
Parts List
NO. PART NAME PART CODE SPECIFICATION REMARK
B01 CABINET 3610809600 PAINTED STEEL SHEET 0.6T
B02 HANDLE CABINET 3612603300 PP
B03 PLATE UPPER 3614521600 PP
B04 BASE U
3610389100PP LOW H=45 DWF-600M
B05 LEG ADJUST AS 3617702100 DWF-1089W2
B06 LEG FIX 3612100310 SBR
B07 HOLDER SUPPORT F 3613044600 FRPP FRONT
B08 HOLDER SUPPORT B 3613044500 FRPP REAR
B09 COVER BACK 3611413600 SPG 0.4T
B10 COVER UNDER 3611418500 PP OPTION
B11 HARNESS OUTER 3610068700 50/0.18GREEN ST710489-2 2-WIRE POWER CORD
B12 HOSE DRAIN O AS 3613213500 LDPE L=833 NON-PUMP
B13 HOSE DRAIN O AS 3613218800 LDPE/EVA L=1600 PUMP
PUMP
B14 GUIDE DRAIN HOSE 3612502300 PP
B15 FILTER AS
3611904900 DWF-800WNP E-TYPE ASKOLL PUMP
3611901530 DWF-5590DPNE E-TYPE DMI PUMP
B16 COVER PUMP 3611405320 PP DMI PUMP
B17 COVER PUMP
3611419100 V0 ASKOLL 220-240V/50Hz
ASKOLL PUMP
3611419200 HB 110V,220V/60Hz
3963514000 AC 220-240V/50Hz
MOTOR SHADED POLE
3963514001 AC 220V/60Hz
DMI PUMP
3963514002 AC 110V/60Hz
B18 3963514003 AC 127V/60Hz
3618958900 AC 220-240V/50Hz
UNIT DRAIN PUMP 3618959000 AC 220V/60Hz ASKOLL PUMP
3618959100 AC 110-127V/60Hz
