29
PARTS DIAGRAM
§§
è
Parts List
NO. PART NAME PART CODE SPECIFICATION REMARK
C01 BALANCER AS 3616104700 DWF-6010
C02 TUB I 3618808500 SUS 0.5T
C03 TUB U 3618808601 PP
STAINLESS STEEL
C04 GUIDE FILTER 3612507000 DWF-6010NP
C05 SPECIAL SCREW 3616003700 SUS 5.5X16
C06 PULSATOR AS 3719706700 DWF-800WNP
C07 BALANCER AS 3616104500 DWF-5510PN
C08 TUB I 3618808100 PP
PLASTIC
C09 GUIDE FILTER 3612503900 PP
C10 PULSATOR AS 3619706600 DWF-750WTP
C11 FILTER AS 4505E82002 POLYESTER 90X120 INSERT
C12 SPECIAL SCREW 3616002901 SUS 304 NON-SILOCK
C13 SPECIAL NUT 4507D83080 SUS 304
C14 FLANGE TUB 3617201100 5KG 3-FOOT
C15 SPECIAL SCREW 4505E05040 5X24
To Next Page
