PARTS DIAGRAM
§§
è
Parts List
NO. PART NAME PART CODE SPECIFICATION REMARK
D01 COVER TUB O 3611414600 PP
D02 TUB O 3618817600 PP
D03 SUSPENSION AS F 3619804200 FRONT
D04 SUSPENSION AS B 3619804300 REAR
D05 VALVE DRAIN AS 3615408500 DWF-750M
NON-PUMP
D06 HOSE DRAIN I AS 3613227000 LDPE+EVA DWF-752MN
D07 HOSE DRAIN I AS 3613226900 LDPE+EVA DWF-800WNP PUMP
D08 CLAMP 4507D08150 MFZN HOSE ID=7PIE
OPTION : PUMP
D09 HOSE 4500D08210 ID=4.0
D10 CLAMP 4507D08150 MFZN HOSE ID=7PIE
OPTION : BUBBLE
D11 HOSE 4500D08210 ID=4.0
D12 BASE 3610302900 SECEN 1.2T
D13 SPECIAL SCREW 3616007000 SCM24H 6.5X24
D14
MOTOR SYNCHRONOUS
3966010410 220-240V/50,60Hz ST=23
3966320830 100-127V/60Hz ST=23
D15 GEAR MECHANISM 3617307310 GM-0600-KJ4P0
D16 BOLT HEX 7640802011 6B-1 8X20 SW MFZN
D17 PROTECTOR GEAR 3618303600 SGCC 1.2T
D18 SPECIAL WASHER 4505E34030 PP
3618959900 110-127V/60Hz W1D30CC004
D19 UNIT MOTOR AS 3618960100 220V/60Hz W1D0UC004
3608960200 220-240V/50Hz 30VC004
D20 BOLT HEX 7650802511 6B-1 8X25 HS MFZN
D21 PULLEY MOTOR AS
3618401420 DP=53.0 50Hz ALDC AC220-240V/50Hz
3618402800 DP=48.5 60Hz ALDC AC220V/60Hz
D22 PULLEY MOTOR AS 3618432000 DP=48.5 60Hz PRESS
D23 WASHER SPRING 7401008011 SW-8 MFZN AC110V~127V/60Hz
D24 NUT HEX 7392800011 M8XP1.25 MFZN
D25 BELT V
4507D34020 M20 50Hz
4507B34020 M19.5 60Hz
D26
HARNESS EARTH INNER
3612757010 L=560
