PARTS DIAGRAM
NO PART CODE PARTS NAME EA DESCRIPTION REMARK
C12 3611502800 CUSHION DOWN 2 POM H=18mm
3964220400 AC 110V/60Hz F34-C
3964820510 AC 127V/60Hz F36-C
C13 3610019700 MOTOR CONDENSER 1 AC 220/60Hz F3A-C
3964310510 AC 220V/50Hz F32-1C
3964610310 AC 240V/50Hz F33-1C
C14 3611502000 CUSHION UPPER 2 POM
C15
3618401400
PULLEY MOTOR AS 1
ADC-12, DS=10, DP=48.5 60Hz
3618401420 ADC-12, DS=10, DP=53.0 50Hz
C16
3613218500 HOSE DRAIN AS 1 PE-LD/EVA, L=219.5 NON-PUMP
3613212100 HOSE DRAIN I 1 PE-LD/EVA, L=184 PUMP
C17 3617301000 GEAR MECHAISM 1 GM-6685D, NTN
C18 3618300100 PLATE GEAR PROTECTOR 1 SBHG 1.6T
C19 - - - -
C20 4507D34020 BELT V 1 M20 50Hz, 60Hz
C21 3610906200 CAP PULSATOR 1 PP
C22 4505E3203A SC PULSATOR FIX AS 1 6x26.5 O-RING+SILOCK
C23 3610906400 CAP 1 PP
C24 3610085500 ASS¡flY FILTER 1 PP(NYLON 74x130)
C25 3619702900 PULSATOR AS 1 PULSATOR+INSERT
C26 4509G83081 NUT-SPIN SHAFT 1 ZDC2 CU, NI COATING
C27 4509L83070 SPECIAL WASHER 1 SUS304 T2.0 PI44
C28
3610009900
BALANCER AS 1
DWF-7590R DWF-7589series
3616101600 DWF-8080R2 DWF-8089series
C29
3618800301 TUB INNER
1
PP DWF-7589series
3618801700 TUB YUS 430D DWF-8089series
C30 3618802000 TUB U 1 PP DWF-8089series
C31 3617200200 FLANGE TUB 1 ADC 12
C32
3612500100 GUIDE FILTER
1
PP DWF-7589series
3612502200 GUIDE FILTER AS DWF-8080R2 DWF-8089series
