PARTS DIAGRAM
2. DWF-9289, DWF-1089
NO PART CODE PARTS NAME EA DESCRIPTION REMARK
A01 3611611400 DECORATOR PANEL F 1 PC FILM 0.188T
A02 3614215300 PANEL F 1 ABS
PRPSSWN500 DWF-1089 NON-PUMP
A03 PRPSSWN800 P.C.B ASS¡flY 1 DWF-1089CTE NON-PUMP
PRPSSWN900 DWF-1089PT PUMP
A04 3614502100 PLATE T 1 ABS
A05 3610906700 CAP 2 ABS
A06 3616001200 SPECIAL BOLT 2 T1 TRS 5x73
3610031411 AC 110-130V/60Hz
A07 3610014711 BUBBLE PUMP ASS¡flY 1 AC 220-240V/50Hz
3610031401 AC 220V/60Hz
A08
3614201000
PANEL B 1
ABS
3614201540 ABS SINGLE VALVE
A09 3610902600 CAP REAR 2 CR
A10 3611105400 CASE DETERGENT 1 ABS
A11 3612300110 GASKET VALVE 2 PVC-S
1EA;SINGLE VALVE
5EP1048010 T5-V1 (AC 110-130V)
A12
5EP1048020
TRANS POWER 1
T5-V1F(AC 110-130V) FUSE
5EP1048030 T5-V2 (AC 220-240V)
5EP1048040 T5-V2F(AC 220-240V) FUSE
A13 3615103500 SPRING 1 SUS 304 D=2.0 RIGHT
A14 3612900400 HINGE LEFT 1 POLYACETAL
A15 3612900300 HINGE RIGHT 1 POLYACETAL
A16 3615103600 SPRING 1 SUS 304 D=2.0 LEFT
A17 3619007800 SWITCH DOOR AS 1 DWDS-01
A18
3610400800
BASE DETERGENT 1
PP
3610400820 PP SINGLE VALVE
A19 3619006710 SWITCH SAFETY 1 DC 15V 10mA
A20 3611405910 COVER R 1 ABS RIGHT
A21 3610903000 CAP DOOR AS 2 80¡flS, 88¡flS
A22 3619005110 SWITCH PRESSURE 1 KANBAYASHI(PS-D7)
A23 3611716800 DOOR F 1 ABS
A24 3611716900 DOOR B 1 ABS
A25 3612602600 HANDLE DOOR 1 ABS
