Components disassembly pictures
6. Evaporator
1. ERF-310A, 340A, 370A, 310M,
340M, 370M
1) Detach Fuse Temp and Defrost Heater harness
using a flat screwdriver.
3) Remove 2 welded points
2) Detach Swich Bi-Metal (M-type) or D-sensor
(A-type) harness by pressing the housing
with the fingers
2) Take out Fan Motor by pressing the housing
