INSTALLATION
1. The recommended installation height is 2.5-3m for best
fog performance.
2. Make sure the product is tightly fixed on the supported
bracket before connecting to the control switch.
3. Do not power on the device and make sure that the
control switch is in the off-state until the installation and
debug is completed.
4. Do not touch the physical casing or nozzle immediately
after the smoke triggered in case of severe burns.
5. Before replacing the smoke cartridge, you must first
check whether the equipment is normal, then replace it to
avoid false triggering.
Précautions d’installation
