6. PART-LIST OF SOLID DOOR MODEL
Caster
CASTER 30265L0200 TP5040-22-HDP
CASTER BRAKE 30265L0100 TP5040-22-HDP-TLB
Compressor
COMPRESSOR Please refer to page No. 14
POWER RELAY (COMP. RELAY) 30281H0310 115V,127V G7L-1A-TUB(OMRON)
POWER RELAY (COMP. RELAY) 30281H0320 220V/60Hz G7L-1A-TUB(OMRON)
ELECTRICAL BOX HARNESS 30277L0802 115V
ELECTRICAL BOX HARNESS 30227L2002 115V/127V
ELECTRICAL BOX HARNESS 30227L2202 220V/50Hz
ELECTRICAL BOX HARNESS 30227L2020 220V/50Hz
ELECTRICAL BOX HARNESS 30227L1702 115V,127V
ELECTRICAL BOX HARNESS 30227L1702 220V/60Hz
ELECTRICAL BOX HARNESS 30227L2202 220V/60Hz
ELECTRICAL BOX HARNESS 30227Q1100 115V
ASSEMBLY P-RELAY
Please refer to page No. 14, 15
CAPACITOR
HARNESS COMP. 30227L0502
HARNESS COMP. 30227L0602
HARNESS COMP. 30227L2800
HARNESS COMP. 30227Q1401
HARNESS COMP. 30200L3400
Condenser
CONDENSER COIL 30200L4001
CONDENSER COIL 30200L4102
CONDENSER COIL 30200L4202
CONDENSER COIL 30200L4303
CONDENSER COIL 30200Q3500
CAPILLARY TUBE 30244Q0301 C1220T L950*OD2.4*ID1.2
CAPILLARY TUBE 30244L1302 C1220T L950*OD2.4*ID1.2
CAPILLARY TUBE 30244Q0401 C1220T L3378*DO2.8*ID1.6
CAPILLARY TUBE 30244L1403 C1220T L4425*OD3.2*ID2.0
CAPILLARY TUBE 30244Q1000 C1220T
L2263*OD4.76*ID3.56
CAPILLARY TUBE(C) 30244Q1100 C1220T L3505*OD3.2*ID2.0
CONDENSER DRYER Please refer to page No. 15
223223
223223
1111
11
111
1
1
1
1
1
1
1
11
1
1
1
1
1
1
1
11
1
1
1
1
1
11
1
Part name Code Material Description
Model
ABCDEF
A : FD,SD-650R B: FD,SD-1250R C : FD-1900R D : FD,SD-650F E : FD,SD-1250F F : FD-1900F
