Daewoo FD Series User Manual

28
PART-LIST OF SOLID DOOR MODEL
Condenser Fan
CONDENSER FAN MOTOR BLADE 30218B0100 AL ø225
CONDENSER FAN MOTOR BLADE 30218A0100 AL ø250
CONDENSER FAN MOTOR Please refer to page No. 16
Door
DOOR BUSHING 30207H1000 PA-6
DOOR ASSEMBLY(LEFT) 30200L26001
DOOR ASSEMBLY(LEFT) 30200L2400 115V
DOOR ASSEMBLY(LEFT) 30200L2410 127V
DOOR ASSEMBLY(LEFT) 30200L2420 220V
DOOR ASSEMBLY(MIDDLE) 30200Q2320
DOOR ASSEMBLY(MIDDLE) 30200Q2330 115V
DOOR ASSEMBLY (RIGHT) 30200L27001
DOOR ASSEMBLY (RIGHT) 30200L3100
DOOR ASSEMBLY (RIGHT) 30200L2900 115V
DOOR ASSEMBLY (RIGHT) 30200L2910 127V
DOOR ASSEMBLY (RIGHT) 30200L2920 220V
DOOR ASSEMBLY (RIGHT) 30200L2500 115V
DOOR ASSEMBLY (RIGHT) 30200L2510 127V
DOOR ASSEMBLY (RIGHT) 30200L2520 220V
DOOR GASKET 30223L0211 PVC-S
CABINET FRAME HEATER 30228L0111 115V/45W L=4100mm
CABINET FRAME HEATER 30228L0131 127V/45W L=4100mm
CABINET FRAME HEATER 30228L0151 220V/45W L=4100mm
CABINET FRAME HEATER 30228L0203 115V/60W L=5500mm
CABINET FRAME HEATER 30228L0241 127V/60W L=5500mm
CABINET FRAME HEATER 30228L0251 220V/60W L=5500mm
CABINET FRAME HEATER 30228Q0101 115V/75W L=6700mm
DOOR HINGE SPRING 30251L0100 ø3.8
MULLION COVER 30214Q2500 STS430
MULLION HEATER 30228Q0300 115V/25W L=2520mm
MULLION HEATER 30228L0903 115V/20W L=2520mm
MULLION HEATER 30228L0911 127V/20W L=2520mm
MULLION HEATER 30228L0921 220V/20W L=2520mm
DOOR HINGE TOP ASSEMBLY LEFT 30229L0800 SPCC,T3.0 MFZN(WH)
11 2
111
246246
11
11
1
1
1
1
11
1
1
1
1
11
1
1
123123
11
11
11
11
11
11
11
123123
12 12
22
11
11
11
11 11
Part name Code Material Description
Model
ABCDEF
A : FD,SD-650R B: FD,SD-1250R C : FD-1900R D : FD,SD-650F E : FD,SD-1250F F : FD-1900F
