PART-LIST OF SOLID DOOR MODEL
EVAPORATOR DRAIN PAN HEATER 30228L1400 115V/90W L=6225mm1
EVAPORATOR DRAIN PAN HEATER 30228L1420 127V/90W L=6225mm1
EVAPORATOR DRAIN PAN HEATER 30228L1430 220V/90W L=6225mm1
DRAIN HOSE HEATER 30228L1310 115V/10W L=W700mm,H350mm
DRAIN HOSE HEATER 30228L1320 127V/10W L=W700mm,H350mm
DRAIN HOSE HEATER 30228L1330 220V/10W L=W700mm,H350mm
DRAIN PAN INSULATOR 30233L0100 E-PS
DRAIN PAN INSULATOR 30233L0200 E-PS
DRAIN PAN INSULATOR 30233Q0100 E-PS
EVAPORATOR FAN MOTOR GUARD 30214K0100 ABS
EVAPORATOR FAN MOTOR BLADE 30218F0200 AL ø175
EVAPORATOR FAN MOTOR 3963328120 115V/60Hz IS-4420DWSN-2A
EVAPORATOR FAN MOTOR 3963328310 127V/60Hz IS-4420DWSO-O
EVAPORATOR FAN MOTOR 3963328010 220V/60Hz IS-4420DWSL-S
EVAPORATOR FAN MOTOR 3963328200 220V/50Hz IS-8417DWSF
DUCT(A) 30267L0106 STS 304-2B1
DUCT(B) 30269L0508 STS 304-2B1
DUCT(A) 30269L0607 STS 304-2B
DUCT(B) 30269L0306 STS 304-2B
DUCT(A) 30269Q0500 STS 304-2B1
DUCT(B) 30269Q0400 STS 304-2B1
THERMOSTAT 30283L0100 40.1˚F ON K55Q-5607, 16A
Top Grille Panel
TOP GRILLE PANEL ASSEMBLY 30200Q3810
TOP GRILLE PANEL ASSEMBLY 30200Q4010
TOP GRILLE PANEL ASSEMBLY 30224L0102
TOP GRILLE PANEL ASSEMBLY 30224L0202
TOP GRILLE PANEL ASSEMBLY 30224L0302
TOP GRILLE PANEL ASSEMBLY 30224L0403
TOP GRILLE 30224L0610 ABS BLACK/GRAY
TOP GRILLE 30224L0510 ABS BLACK/GRAY
TOP GRILLE 30216Q1600 ABS BLACK/GRAY
PCB HARNESS 30227L1001
FRONT LABEL 30235Q1000 PC,T0.254 ˚C / ˚F
FRONT LABEL 30235L0110 PC,T0.255 ˚C / ˚F
1
1
1
111
11
11
11
11
11
122122
122122
122122
12 12
12 12
12 12
11
11
11
11
11
11
11
1
1
1
1
1
1
11
11
11
1111
1
111
Part name Code Material Description
Model
ABCDEF
A : FD,SD-650R B: FD,SD-1250R C : FD-1900R D : FD,SD-650F E : FD,SD-1250F F : FD-1900F
