PART-LIST OF SOLID DOOR MODEL
DOOR LOCK (KEY) 30238G0100
CONTROL BOARD HOUSING 30242L0110 ABS BLACK, Turbo air
DISPLAY PCB 30243L0110 ˚C / ˚F
DISPLAY PCB 30243Q0200 ˚C / ˚F
MAIN PCB Please refer to page No. 18
POWER SWITCH (ROCKER SWITCH) 30281Q0100 125V/15A
DOOR SWITCH 30281L0100 SP201R-10D
THERMOMETER 30283L1000
TRANSFORMER Please refer to page No. 17
Bottom Grille
BOTTOM GRILLE ASSEMBLY 30223L1410 STS304-HL
BOTTOM GRILLE ASSEMBLY 30224L1400 STS305-HL
BOTTOM GRILLE ASSEMBLY 30200Q4100 STS304-HL
Lamp
LAMP SHIELD 30214L3200 PP MILKY
LAMP HARNESS 30227L0900
LAMP BULB Please refer to page No. 17
LAMP SOCKET 30279L0100
MEDIUM BASE L-124B-PVC
Shelf
SHELF STANDARD 30220L1001 STS304-2B T0.8, L=1219
SHELF CLIP 30220L0900 PA-616
SHELF 30278L0100 PE+
SHELF 30278L02008 PE+
SHELF 30278Q0220 PE+
SHELF 30278Q0240 PE+
SHELF STANDARD (REAR POST ASSEMBLY) 30245Q0400 AL+STS L=1308
SHELF STANDARD (REAR POST ASSEMBLY) 30245Q0410 AL+STS L=1270
COLD AIR FLOW GUIDE WIRE 30269Q0600 PE+
ABCDEF
Part name Code Material Description
Model
123123
1111
111
1
1111
123123
11
11
11
11
112112
112112
112112
484484
16 32 36 16 32 36
44
88
12
12
22
22
6
A : FD,SD-650R B: FD,SD-1250R C : FD-1900R D : FD,SD-650F E : FD,SD-1250F F : FD-1900F
