Refrigerator Leveling &
Door Adjustment
(If needed)
※ The refrigerator must be level in order to maintain
optimal performance and desirable front appearance.
(If the floor beneath the refrigerator is uneven, the freezer
and refrigerator doors look unbalanced.)
In case freezer door is lower than
refrigerator door...
Insert a screw driver (flat tip) into a groove of the left
wheel (bottom of freezer) and turn it clockwise until
the door is balanced. (Clockwise to raise freezer door,
counterclockwise to lower.)
※ If the freezer door is not balanced by step 1, then
follow the next steps.
Open the doors, unscrew the front cover and remove, if
it is attached.
Insert a spanner (part A) into the hinge nut (part 1)
and unscrew the nut by turning clockwise.
Insert a spanner (part B) into the hinge nut (part 2)
and turn clockwise to lower the door.
If the door is aligned, fasten the nut (part 1) tightly
by turning counter-clockwise.
In case refrigerator door is lower than
freezer door...
Insert a screw driver (flat tip) into a groove of the right
wheel (bottom of refrigerator) and turn it clockwise until
the door is balanced. (Clockwise to raise refrigerator
door, counterclockwise to lower.)
※ If the refrigerator door is not balanced by step 1, then
follow the next steps.
Insert a spanner (A part) into the hinge nut (1 part) and
unscrew the nut by turning clockwise.
Insert a spanner (B part) into the hinge nut (2 part) and
turn counter-clockwise to tighten the door.
If the door is aligned, fasten the nut (1) tightly by
turning.
■ Front Cover
After installation and/or door leveling, fasten front cover with
screws. (Remove the screws on the front bottom panel first.
Click and screw the cover.)
Caution
●The front of refrigerator needs to be just a little
higher than the back for easy door closing, but if
the wheel is raised too much for door balance,
i.e. the front of refrigerator is much higher than
the back, it can be difficult to open the door.
1
1
2
3
2
4
3
4
5
